Raptor Drivers for Linux Installation and Reference Manual
2-4
The Raptor 2500T card has one connector on the front bracket.
One side of the provided cable has the LFH60 connector that
connects to the graphics card. The cable splits into two with
MDR26 connectors on the opposite end. These two connectors
marked A & B get connected to the appropriately marked
connectors on the back of the digital flat panel. They are shown
in Figure 2-2. On some models of the digital flat panel, the
connectors may be recessed. In this instance, please remove
the back panel, plug the cables into the two marked connectors
and restore the back panel.
