Chapter 3 – Software Installation for I-Class Cards
3-7
Option "Device": This field specifies the device name of the
Raptor card. The first Raptor card seen by
the system will be
/dev/raptor0
and the
second will be
/dev/raptor1
and so on.
For Raptor 2500, the device name will be
rapqfp0
and so on. The device name and
the
BusID
specified earlier in this section
must correspond to the same card.
Option "MOX":
MOX (Multiple Overlay Extension) is a fea-
ture available on Raptor cards that provides
multi-layer capability. Available MOX
modes are mox16 and mox24. The sample
Device
section listed uses mox24 mode.
MOX is disabled by default. Therefore, this
line is commented out in the example given.
See Section 5.6 for more details on
configuring MOX.
If more than one Raptor 2000 or Raptor 2500 card is installed,
a separate
Device
section must be created for each card.
Each
Device
section should have a unique
Identifier
BusID
and
Device
option fields. Other fields should remain
unchanged. For more information please refer to Section 5.5.
3.6.3 Screen Section
Identifier: Each screen must have a unique identifier
which will be used in the
ServerLayout
section.
Device: This field specifies which device you want to
use for this screen. It should match the
Identifier specified in one of the
Device
sections.
If multiple Raptor cards are installed, additional
Screen
sections should be created. Each
Screen
section should
have a unique identifier. For more information please refer to
Section 5.5.
