Function: Dub Output Level
Byte Value Description
1 F0H System-Exclusive Message
2 00H 1st Byte of Studio Tech ID
3 00H 2nd Byte of Studio Tech ID
4 56H 3rd Byte of Studio Tech ID
5 01H Product ID (Model 50)
6 02H Function: Output Level
7 0nH Output Channel, range 1, 1=dub out
8 0nH Output Level, range 0-1, 0=–10, 1=+4
9 F7H EOX, End of System Exclusive
Function: Control Room Source
Byte Value Description
1 F0H System-Exclusive Message
2 00H 1st Byte of Studio Tech ID
3 00H 2nd Byte of Studio Tech ID
4 56H 3rd Byte of Studio Tech ID
5 01H Product ID (Model 50)
6 03H Function: Control Room Source
7 mnH Source Selected, m range 0-2: 0=stereo, 1=left only, 2=right only;
n range 0-7: 0=no input, 1=input 1, 2=input 2, etc.
8 F7H EOX, End of System Exclusive
Function: Studio Source
Byte Value Description
1 F0H System-Exclusive Message
2 00H 1st Byte of Studio Tech ID
3 00H 2nd Byte of Studio Tech ID
4 56H 3rd Byte of Studio Tech ID
5 01H Product ID (Model 50)
6 04H Function: Studio Source
7 mnH Source Selected, m range 0-2: 0=stereo, 1=left only, 2=right only;
n range 0-7: 0=no input, 1=input 1, 2=input 2, etc.
8 F7H EOX, End of System Exclusive
Function: Headphone Source
Byte Value Description
1 F0H System-Exclusive Message
2 00H 1st Byte of Studio Tech ID
3 00H 2nd Byte of Studio Tech ID
4 56H 3rd Byte of Studio Tech ID
5 01H Product ID (Model 50)
6 05H Function: Headphone Source
7 mnH Source Selected, m range 0-2: 0=stereo, 1=left only, 2=right only;
n range 0-7: 0=no input, 1=input 1, 2=input 2, etc.
8 F7H EOX, End of System Exclusive
