Model 50/51 User Guide Issue 4, July 2000
Studio Technologies, Inc. Page 23
Model 51 Configuration Chart—Alternate Functions
Press and hold Level
Up to activate alternate
configure functions
Press Talk to Studio to
toggle phones interrupt
and phones add; LED
on means talk to
phones is add
Press and hold Phones/Studio, then press
CR/Studio 1 to toggle between normal
headphone source and headphones
follow control room source; LED on
means headphones follow control room
Press Slate to toggle to
50Hz slate tone; LED on
means 50Hz tone is on
Press Talk to Phones to
toggle slate feed to
phones; LED on means
slate to phones is on
Press and hold Phones/
Studio, then press CR/
Studio 2 to toggle between
normal dub source and dub
follows control room source;
LED on means dub follows
control room
Press and hold Phones/Studio,
then press CR/Studio 3 to
configure remote control room
source select; LED on means
function enabled
Press and hold Phones/Studio,
then press CR/Studio 4 to
configure channel associated
with remote control room
source select; LED off means
channel 6 selected; LED on
means channel 7
