PONDEROSA
93
Multi-Frame Connection
The Ponderosa Audio routing switcher is connected to the Ponderosa video router to work as one
system.
Depending on the other frames in the system, connections are either made using the “J1” (25 pin)
or “Multi-drop” (9 pin) connector. A system drawing will be included in the shipment if a multi-
frame system is ordered.
Control panels and serial control connect to the frame containing the master processor.
Note:
The 9 pin Multi-drop connection is not a serial connection.
Ponderosa Video
Master Frame
Multi Drop 1 or J1
Ponderosa Audio
Slave Frame(s)
Multi Drop or J1
Control Panels, RS-232/422 Serial
Control, IP, and Ethernet control Connect
to this Frame
Multi-Frame Interconnect Cable
