PONDEROSA
111
Analog Audio Specifications
Gain +/- 0.5 dB
Frequency Response: 20 Hz to 20 KHz +/- 0.5 dB
Max I/O Level- Balanced +21 dB
Max I/O Level- Unbalanced +15 dB
Noise (20 Hz to 20 KHz) -79 dBu
Crosstalk: 1 KHz < -90 dB
Crosstalk: 10 KHz < -70 dB
THD+N (20 Hz to 20 KHz @ +4 dBu) < 0.025%
IM (20 Hz to 20 KHz @ +4 dBu < 0.025%
Digital Audio Specifications
AES 3 AES 3-id
I/O connections 110 ohm balanced/shielded cable 75 ohm BNC
Input/Output impedance 110 ohm +/- 20% 75 ohm
Return Loss < -15 db < -15 db
Output Voltage 2 V p-p Min 1 V p-p +/- 20%
DC Offset N/A < 50 mv
Rise/Fall Time 5 to 30 ns 30 to 44 ns
Intrinsic Jitter < 0.025 UI using intrinsic-jitter filter < 0.025 UI using intrinsic-jitter filter
Min Input Voltage 200 mv p-p 320 mv p-p
Data Rates
32 KHz to 96 KHz Sampling Rate
2.048 Mbps to 6.144 Mbps Data Rates
Meets all above specifications with 32 KHz, 44.1 KHz, 48 KHz, and 96 KHz
Sampling Rates
General
Rack Unit/ Frame Size 3RU-6464 Frame & 5RU-128128 Frame
Dimensions
6464 Frame-19” W x 5 1/4” H x 20 1/2” D
128128 Frame 8 3/4” H x 20 1/2” D
Mounts in Standard 19” rack
Depth measurements do not include rear cabling
Power
90VAC to > 240VAC Auto-detecting
<150Watts for 6464 Frame
<300Watts for 128128 Frame
Redundant Power Supply Standard
Storage Temperature -40° to +150° F
Operating Temperature 30° to 100° F Ambient
Humidity 10% to 90% Non-condensing
