SIERRA VIDEO
58
Commonly Used Switching Commands
This section contains the most commonly used switching commands. These commands are
explained in detail in the proceeding section and are merely meant as a “short cut” for
programmers.
“Y” Command- All Levels
The “Y” command switches all levels (i.e. video and audio).
For example;
**Y2,8!!
This string says that input 8 is to be connected to output 2 on all levels.
“X” Command- Specify Levels
Using the “X” command requires that a level is specified.
For example;
**X8, 3, 2!!
This string says that a connection is to be made between output 8 and input 3 on level 2. If a level
number of “0” is used, all levels are switched.
“V” Command- Connect Levels
The “V” command is followed by an output number, a comma, and an input number for each
level, up to the number of levels on the router.
For example;
**V12, 7, 8, 9!!
This string says that connections are to be made to output 12 from input 7 on level 1, input 8 on
level 2, and input 9 on level 3.
Unless otherwise specified at the time of order, the V5S series of routing switchers are configured
at the factory with 7 levels of control as indicated by the chart below.
Level # Type
1 R
2 G
3 B
4 H
Sync
5 V Sync
6 Audio 1
7 Audio 2
Note:
When writing commands for a “third party” controller, pay careful attention to the levels of control.
