OPERATION
29
“Select Room Grouping” Menu
Select System Parameters – Selecting system parameters allows access router configuration
information and to adjust various settings of the 9 pin serial port and control panel port on the rear
of the router. A “Disable Front Panel” option is also contained in this menu.
Adjust Audio Gains – This menu path allows the input gain to be adjusted. The input gain may
be changed from –10db to +20db in .5db to 1db increments. The output gain can be changed
from output mute, -61db to +15db in .5db to 1db increments.
Select Salvo – Allows selection and execution of Salvos stored in the router. A Salvo is a group
of Sources and Destinations that are stored in the routing switcher and switched by a single
“Salvo Take” command. TyLinx Pro Configuration and Routing Software allows up to 256 Salvos
to be named and stored in the routing switcher. The salvo name will be displayed in the Salvo
register. Salvos are made and stored in the router using the Sierra Video Software program
TyLinx Pro.
Adjust A/V muting – A/V muting selects a delay time before audio and video appears after
“Take” is pressed. Sync will be switched with only the audio and video being delayed. The range
of adjustment is from 0 to 10 seconds in .5 second increments.
Select Room Grouping – A room group is a “user defined” group of inputs, outputs and levels.
Room Groupings are configured and stored in the router using the TyLinx Pro program (see the
TyLinx Pro manual for details on creating and storing Room Groups), or Room Groups can be
configured using the serial port (contact Sierra Video for Protocol details).
Switching the Router
Switching AFV (all levels);
 Press [V/A] until the screen displays “Preset AFV” (all levels).
 Press [Select] until “Dst” is flashing.
 Choose the Destination (output) using the rotary knob.
 Press [Select] to cause “Src” to flash.
 Choose the Source (input) using the rotary knob.
 Press [Take] to activate the switch.
Note:
The router can also be switched by selecting the source first by reversing the order of selecting.
Select Room
Grouping
Select Room Examine Sources and
Destinations
