Scotsman 600 Eclipse - Manual (Page 5)

Cabinet Drawings, Ice Making System
Eclipse
ä 600, 800, 1000
April 2002
Page 5
22.00
28.00
6.58
3.46
3.00
1.75 16.75
OPTIONAL REAR ACCESS
LINE SET, WATER INLET, 120V AC,
AND INTERFACE CABLE
OPTIONAL REAR
ACCESS DRAIN
OPTIONAL REAR
ACCESS WATER INLET
REAR VIEW
ICE MAKING SECTION
TOP VIEW
16.50
15.12
8.00
5.00
LEFT AND RIGHT
SIDE ACCESS DRAIN
5.00
16.75
8.00
1.75
TOP ACCESS
LINE SET, WATER INLET, 120V AC,
AND INTERFACE CABLE
ICE DROP AREA
22 "
16 1/2"
2 5/8"
3 3/8"
17 "
19 1/2"
1 1/4"
1 5/8"
1 1/4"
3 "
Outline of unit
Maximum Drop Zone
Minimum Drop Zone
Protrusion Off Bottom
Of Ice Machine
7 3/4"
12 5/8"
5 3/8"
Front View of Base
Top View
Ice Making Section Footprint
Front
Front
