Condensing Unit Connections
Connect the suction line, the vapor line and the
liquid line to the matching fittings on the CP unit.
See Coupling Connections on the prior page for
detailed instructions.
Eclipse
ä 600, 800, 1000
April 2002
Page 25
Assembled Condensing Unit
Control Wire
Power
Supply
Inlet
Field
Supplied
Service
Disconnect
Liquid Line
Suction Line
Vapor Line
