Controller Features & Last Error Recall
Last Error/Diagnostic Light Recall
To recall the last error on the blue housing CM
3
controller:
1. Switch the unit OFF by holding the OFF button
for longer than 3 seconds.
2. Hold the Off button down again until the Purge
Setting indicators (Green Lights) are on.
3. Push and release the Harvest button.
The last error code stored in the controller will be
displayed and the purge setting will disappear.
Push the Harvest button again and the
second-to-last error code will be displayed. The bin
full light will also be on to signal that this is the
second-to-last code.
Pushing the Harvest button again will display the
last error code again. Only two error codes are
available for display.
If no error code exists, no code will be displayed
and there will be NO LIGHTS showing.
To return from the display of the last error, do
nothing for 60 seconds or push and hold the Off
button.
After returning from the display of the last error (Off
light glows), the machine may be returned to the
ice making process by pushing and releasing the
Freeze button.
Controller Diagnostic Codes
If a Diagnostic
Light Water Light Refrigeration
Light
Blinks once and
repeats Water pump will
not start Very long ice
harvest
Blinks twice and
repeats Lack of water fill No harvest of ice
Blinks three
times and
repeats not used High discharge
temperature
Is ON all the time Water valve
leaking thru
rapidly
Maximum freeze
time
Both ON all the
time Check for thermistor set unplugged
or failed
Program ID
The blue housing controller will display a code at
power up that indicates which ice machine model it
has been programmed for.
The code is based on the green lights that are
displayed.
1. At power up all lights flash ON once to indicate
that the controller has passed its internal
self-checks.
2. Immediately after that the program code will be
displayed for 20 seconds or until a button is
pushed.
Note: The proper program code for this machine is
glowing
·
CME810: Bin Full and Harvest lights.
·
CME686: Bin Full, Harvest and Clean lights
Do NOT operate this machine if the wrong code is
displayed.
3. If no button is pushed after 20 seconds the
machine will display the Off light and is ready for
switch inputs (push and release Freeze to start
making ice).
Note: The Red Diagnostic Lights will be
FLASHING while the program ID is displayed.
