35 105501
OWNER’S MANUAL
PARTS LIST
CISC
CISG
This list contains replaceable parts used in your stove. When ordering parts, follow the instructions
listed under Replacement Parts on page 30 of this manual.
* Included In Hardware Kit
KEY PART
NO. NO. DESCRIPTION QTY.
1 104968-01 Stove Back Panel (Black Only) 1
2 104969-01 Bottom Door (Charcoal) 1
104969-02 Bottom Door (Forest Green) 1
3 104174-03 Stove Dropped Bottom 1
4 104970-01 One Leg (Charcoal) (4 Total Per Stove) 1
104970-02 One Leg (Forest Green) (4 Total Per Stove) 1
5 104971-01 Hardware Kit 1
5-1 * Door Hinge Step Bolt With Shoulder (1 Per Unit) 1
5-2 * Door Catch Bolt M8 x 1.25 - 55mm Long With Two M8
Hex Nuts (1 Per Unit)
1
5-3 * Bottom Floor Bolts M6 x 1 - 25mm Long With Flat Washer
And Lock Washer (4 Per Unit)
1
5-4 * Leg Attachment Stud, Headless, Slotted,
M10 x 1.5 - 40mm Long
4
7 104178-01 Back Panel Bolts M6 x 1 - 20mm Long With Flat Washer
And Lock Washer (6 Per Unit)
1
PARTS AVAILABLE — NOT SHOWN
104108-08 Touch-up Spray Paint 12 oz Can (Charcoal) 1
104108-05 Touch-up Spray Paint 12 oz Can (Forest Green) 1
