31 105501
OWNER’S MANUAL
SPECIFICATIONS
CDVBN(A) CDVBP(A)
16,000-22,000 Btu/hr 14,000-20,000 Btu/hr
Gas Type Natural Propane/LP
Ignition Piezo Piezo
Manifold Pressure 3.5" w.c. 10.0" w.c.
Minimum Inlet Supply Pressure 4.5" w.c. 11.0" w.c.
Thermal Efficiency 70% 70%
Dimension, Inches/mm (HxWxD)
Stove and Burner System* 26 1 /
2
" x 25" x 25 5 /
8
" 26 1 /
2
" x 25" x 25 5 /
8
"
673.1 x 635 x 650.7mm 673.1 x 635 x 650.7mm
Carton (Insert Only) 23 1 /
4
" x 33 1 /
4
" x 23 1 /
2
" 23 1 /
4
" x 33 1 /
4
" x 23 1 /
2
"
590.5 x 844.5 x 596.9mm 590.5 x 844.5 x 596.9mm
Weight, lbs/kg
Burner System 70 lbs/31.8 kg 70 lbs/31.8 kg
Shipping 75 lbs/34 kg 75 lbs/34 kg
* When installed in Comfort Glow cast iron stove body (CISGA Series and CISCA Series).
ACCESSORIES
Purchase these stove and burner system
accessories from your local dealer. If they
can not supply these accessories, call DESA
International’s Sales Department at 1-800-
432-2382. for information. You can also
write to the address listed on the back page
of this manual.
MANUAL BLOWER KIT
GA3750
Manual-variable control blower accessory
for both the CDVBN(A) and CDVBP(A)
Series burner systems.
THERMOSTATICALLY-
CONTROLLED BLOWER KIT
CDA3620T
Provides better heat distribution. Blower
turns off and on automatically, as needed.
Complete installation and operation instruc-
tions included in this manual.
AUT O
MAN
OFF
ST ATUS
ON
LO
HI
TEMP
RECEIVER AND HAND-HELD
REMOTE CONTROL KIT
CGHRC SERIES
For all models. Allows the burner system to
be turned on and off conveniently.
RECEIVER AND HAND-HELD
THERMOSTAT REMOTE
CONTROL KIT - CGHRCT
SERIES
Allows the burner system to be operated in
a manually or thermostatically-controlled
mode. You can adjust your heat settings and
turn the burner system on or off without
leaving the comfort of your easy chair. (Re-
quires part no. 103284-04 wire harness in-
cluded with burner system.)
