3 105501
OWNER’S MANUAL
LO HI
OFF
ON
ON
OFF
AUTO
PRODUCT
IDENTIFICATION
Install and use stove and burner system with
care. Follow all local codes. In the absence
to local codes, use the current National Fuel
Gas Code ANS Z223.1, also known as
NFPA 54* (USA) or the current CAN/CGA-
B149[.1 or .2] Installation Codes (Canada).
*Available from:
American National Standards Institute, Inc.
1430 Broadway
New York, NY 10018
National Fire Protection Association, Inc.
Batterymarch Park
Quincy, MA 02269
LOCAL CODES
PRODUCT
FEATURES
OPERATION
This cast iron stove with burner system is
clean burning and vents easily through out-
side walls or vertically using outside air for
combustion. Heat is generated by both real-
istic flames and glowing embers. When
used without the blower accessory, the stove
with burner system requires no electricity
making it ideal for emergency backup heat.
PIEZO IGNITOR
This burner system has a piezo ignitor. This
system requires no matches, batteries, or
other sources to light burner system.
Figure 1 - Comfort Glow Direct-Vent Burner System Shown Installed in Approved
Comfort Glow Cast Iron Stove Body Models CISGA Series and CISCA Series Only
GLOSSARY OF
TERMS
Chase - A boxlike enclosure to protect
venting from the elements when the venting
run is on the outside of a structure.
Mastic - A pliable sealant for use around the
vent terminal.
Snorkel Termination - A box that raises the
horizontal termination above ground level
clearances.
Vent Terminal - Mounted on an outside
wall or roof to separate the inlet and outlet of
the vent system and protect it from weather.
Vinyl Siding Standoff - A metal box that
separates the vent cap from vinyl siding.
Wall Thimble/Firestop - A metal plate used
to secure the vent pipe when it passes through
a wall or ceiling.
Cast Iron
Stove Body
Blower with
Adjustment
(Optional
Installation)
ON/OFF
Switch
Piezo Ignitor
Control Valve
Log Set
Lava Rock
Pilot Assy
Burner
Vent
Opening
Glass Door
Assy
Glowing Embers
Grate Assembly
Rear Cover
Cast Iron
Stove Body
