Page 33
33
105501
OWNER’S MANUAL
KEY
NO.
PART NUMBER
DESCRIPTION
QTY.
1
105478-02BR
Firebox Assembly
1
2
M11084-26
Screw, Hex
2
3
105482-02CK
Rear Cover
1
4
M11084-39
Screw, Hex
12
5
103587-02CK
Switch Plate
1
6
099998-01
On/Off Switch
1
7
103284-04
Wire Harness
1
8
104491-01
Relief Cover
1
9
104518-01
Relief Cover Gasket
1
10
104527-01
Relief Spring
2
11
104528-01
Relief Washer
2
12
H5C4-20B
Hex Head Cap Screw
2
13
NTC-4C
Locknut
2
14
105468-01
Valve Bracket
1
15
105487-01
Valve, Natural
1
105487-02
Valve, Propane/LP
1
16
105486-01
Pilot Assembly, Natural
1
105486-02
Pilot Assembly, Propane/LP
1
17
102445-01
Ignitor, Piezo
1
18
102334-01
Palnut Fastener
1
19
105523-01
Burner, Natural
1
105523-02
Burner, Propane/LP
1
20
104506-01
Orifice, Natural
1
104506-02
Orifice, Propane/LP
1
21
104507-01
Brass Elbow
1
22
104508-01
Brass Fitting
2
23
105493-01
Aluminum Tubing Assy
1
24
104510-01
Pilot Tubing Assembly
1
25
105325-01
Air Deflector
1
26
105492-01
Log Set
1
26-1
105773-01
Rear Log
1
26-2
105773-02
Front Log
1
26-3
105773-03
Left Log Piece
1
26-4
105773-04
Right Log Piece
1
27
M10908-2
Screw
18
28
M12461-50
Screw
3
29
M12461-62
Screw
2
30
104555-03CJ
Grate Assembly
1
31
105483-01
Burner Bracket
1
32
105795-01
Glass Door Assy
1
GA6060
Lava Rock
1
104529-01
Ember Material
1
M11084-3
Hex Screw for Blower Bracket
4
PARTS AVAILABLE - NOT SHOWN
PARTS LIST
CDVBN(A)
CDVBP(A)
This list contains replaceable parts used in your burner system. When ordering parts, follow the
instructions listed under Replacement Parts on page 30 of this manual.
