6. System Setup and Operations
Single Image Switching
VSP 729 User Manual 86
If it is just simple seamless effects switch between stage pictures, the
settings above are basic completed, just save the existing information and
master switch skills in practice, as follows:
Button Save User Mode Operations
Press CUSTOM and【SAVE】，Six light below SAVE CONFIG lights on is
SAVE1~6，Press 【1】,it means the current parameters is saved to
mode1.When restart the mode1 is defaulted.
Single Image Switch
VSP729 can arbitrary seamless effect switch between 4 channel,Just
choose the channel need to switch to screen firstly.If the light 3 below
Program lights on.It means the screen output the channel3 signal. If need
to switch channel2 signal to the screen,Press 【2】 below Preview,And
seamless effect switch or Press 【TAKE】
【TAKE】default for 3 seconds fade-in fade-out，If need to switch the time
of fade-in fade-out,please Press【FADE】to change the time through the
knob switch,and Press NEXT to affirm.Press TAKE again to recover.If need
to switch other channel signal please Press the corresponding reface 【1】、
【2】、【3】、【4】 below Preview and Press【CUT】or【TAKE】to out.
Size and Position setting
For different channels the size and position is different，VSP729 can realize
the different channel image size and position alone to adjust
arbitrarily .Press the corresponding signal below Preview such as select
