RGBLink VENUS X1 Quick Start - Manual (Page 6)

Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen,Fujian Province, P.R.C
Tel: 00865925771197 Fax: 00865925771202
Email: [email protected] http://www.rgblink.cn
5
Back Panel
Input Interface
10 HDMI Input HDMI-A port
11 CVBS Input BNC port
12 VGA Input DB15 port
13 DVI Input DVI-I port
Other Interface
1. 2. 3 S/V/D/C/U/H/Audio input module
4 Dial switch
5 10/100M Interface
6 USB Interface USB-B port
7 RS232 Interface
8. 17 Sending card interface
9 Power Switch
18 Power IEC-3
Output Interface
14 DVI/DVI LOOP Output DVI-I port
15 DVI Output DVI-I port
16 VGA Output DB15 port
