27
d. Recommended Additional settings:
i. Echo Typed Character Locally
ii. Send line Ends with Line Feeds
iii. Append Line Feeds to Incoming Line Ends.
e. If the terminal software is correctly set up then the unit will respond with a
prompt
>
if the
f. Consult the Operations manual for full list of applicable serial commands.
g. Example: Checking optical input power level via serial terminal software:
i. Enter the text:
RIP
ii. The unit will respond with text similar to:
>Input Power = 6.2 dBm
Which in this case reports that the input power is 6.2 dBm (4.2 mW).
h. It is important to correctly configure the TCP/IP settings of the unit, via the se-
rial interface, for correct operation on the installation site LAN for SNMP com-
munication.
i. Login to gain access to provisioning commands:
LOGIN 999999
where 999999 is the default login password, actual password may have
been changed by operators. Note: if you do not login then you can still
read settings but will not be able to change/write provisioning settings.
ii. Set fixed TCP/IP address of unit
SIP xxx.xxx.xxx.xxx
where xxx.xxx.xxx.xxx is the fixed TCP/IP address that has been desig-
nated for this unit at this installation site.
iii. Set the TCP/IP Gateway address that the unit may use
SGATE yyy.yyy.yyy.yyy.yyy
where yyy.yyy.yyy.yyy.yyy is the fixed TCP/IP address that has been
designated as the gateway for the unit at this installation site.
iv. Set the TCP/IP subnet mask the unit
SNET zzz.zzz.zzz.zzz
where zzz.zzz.zzz.zzz is the TCP/IP sub-net mask that has been desig-
nated for the unit at this installation site.
