D-Link Product Guide 2008
Features & Benefits
MOBILE
COMMUNICATION
Features & Benefits
D-Link Product Guide 2008
MOBILE
COMMUNICATION
3g / 3.5g MoBile
AdApters & routers
The 3G/3.5G mobile adapters and routers provide broadband access for mobile
workgroups. Instead of connecting to a DSL or cable landline, they use the 3G/3.5G
services of mobile network operators. These adapters and routers are ideal for mobile
PC users, work teams, emergency response units, and corporate commute vehicles
that need to provide an Internet connection while on the move. As they are affordable
in price, they can also be used by 3G/3.5G service subscribing consumers to connect
to the Internet or set up hot spots without being tied to a single location. They allow
users to access private networks away from the office where a cable or DSL Internet
connection is not available.
● Wireless Networking on the Go
» Creation of wireless network for co-
workers to remote access office network
from a remote site.
» Wireless Internet access for passengers
on train, bus or boat.
● Mobile Video Transmission
» Direct connection of video cameras to
high-speed 3G/3.5G services to upload
pictures from a web camera as the car
is driven around.
● Internet Access from 3G/3.5G
Service Subscribers
» Share Internet among home users
where DSL or cable broadband wired
connection is not available.
● Emergency/Mobile
Applications
» Ideal for mobile users in press media,
finance/construction industries, police/
emergency rescue teams, impromptu
LAN parties at airports, hotels,
convention halls.
DWM-652
HSDPA/UTMS/EDGE/GPRS/GSM 3.5G Mobile ExpressCard
● Downstream Data Rates: 7.2M/3.6M/1.8M/1.2M384Kbps *
● Upstream Data Rates: Up to 384bps *
● GSM Band (GSM/GPRS/EDGE): 850, 900, 1800, 1900MHz
● UMTS Band (WCDMA/HSDPA): 850, 1900, 2100MHz
● Automatic HSDPA-WCDMA-GPRS Handover
● Radio Mode Selection: 3G/3.5G for WCDMA/HSDPA, 2G Only for GSM/GPRS/EDGE,
2G+3G/3.5G dual-mode
● Supported Interfaces: ExpressCard, USB Adapter Provided, PCMCIA Adapter Optional
DIR-451
UMTS/HSDPA 3G Mobile Router
● 32-Bit CardBus Slot for Insertion of 3G
Internet PC Card
● Compatible with UMTS and HSDPA
Standard Mobile Networks
● UMTS: Up to 2Mbps Download 768Kbps
Upload Internet Speed*
● HSDPA: Up to 7.2Mbps Download
384Kbps Upload Internet Speed*
● Integrated 802.11g Wireless LAN (Up to
108Mbps Turbo Speed)
● 4 10/100BASE-TX Ethernet Ports for
Computer Connection
● USB 2.0 Port for Windows Connect Now
(WCN) Setup
● WPA EAP/PSK, WPA2 EAP/PSK, TKIP,
AES, 64/128/152-Bit WEP WLAN Security
● MAC/IP Address-Based User Access
Control
● SPI Firewall Protection
DIR-450
● 32-Bit CardBus Slot for Insertion of 3G
Internet PC Card
● Compatible with EV-DO Standard Mobile
Networks
● Up to 2.4Mbps Download 153Kbps
Upload Internet Speed*
● Integrated 802.11g Wireless LAN (Up to
108Mbps Turbo Speed)
● 4 10/100BASE-TX Ethernet Ports for
Computer Connection
● USB 2.0 Port for Windows Connect Now
(WCN) Setup
● WPA EAP/PSK, WPA2 EAP/PSK,
TKIP, AES, 64/128/152-Bit WEP WLAN
Security
● MAC/IP Address-Based User Access
Control
● SPI Firewall Protection
UMTS/HSDPA 3G Mobile Router
WiMAX AdApters &
routers
● Broadband Access
» WiMAX as the “last mile” connectivity at high
data rates.
» Broadband access to places where it has
been economically unavailable.
● Disaster Relief
» Providing broadband access to help
regenerate communication when all
communication infra-structure was destroyed.
● IEEE 802.16e-2005 Standard
» Latest industry specifications ensure a high level
of interoperability with other WiMAX products.
» Lower frequencies used for inherent signal
attenuation and improved range and in-building
penetration.
● Integrated Wi-Fi Sub-systems
» Shorter range wireless access system of a
few hundreds of meters’ radius, using free
unlicensed spectrum to provide access to a
broadband network.
» Wi-Fi used by end-users to access their own
network, which may or may not be connected
to the Internet.
● Integrated Internet Phone (VoIP)
» Voice communication over the Internet WiMAX
broadband connection at no phone charge or
nominal fee.
D-Link WiMAX adapters and routers provide wireless mobile long-range connection,
covering many kilometers of spectrum to deliver Internet connection to WiMAX end
users. These adapters are portable units and connect PC users through a PCMCIA or
USB interface to WiMAX Base Stations deployed by WiMAX Internet Service Providers.
Similarly, the WiMAX routers connect a group of users to WiMAX Base Stations also
deployed by WiMAX ISP. PC users in turn connect to the WiMAX routers through 802.11
Wi-Fi wireless or 802.3u Ethernet interfaces.
D-Link WiMAX provides standard-based broadband services for mobile operators. It
is based on the 802.16e-2005 standard and uses the OFDMA PHY as the interface
technology. It employs Mobile WiMAX implementations and smart antenna subsystems
for guaranteed signal transmission and reception. It can be used to deliver both fixed and
mobile applications to wide-ranging situations, such as:
• Connecting Wi-Fi hotspots with each other and to other parts of the Internet.
• Providing a wireless alternative to cable and DSL for last mile broadband access.
• Providing high-speed data and telecommunications services.
• Providing a diverse source of Internet connectivity as part of a business continuity plan.
If a business has a fixed and a wireless Internet connection, especially from unrelated
providers, they are unlikely to be affected by the same service outage.
• Providing nomadic connectivity.
DIR-462
● Mobile Broadband Connection for
Workgroups
● Dual Dipole Antennas to Boost Signal
Strength
● Integrated 802.11g Wireless LAN
● Integrated Voice over Internet
Communication (2 FXS Ports, SIP
Protocol)
● Built-in 4-Port Ethernet Switch for Wired
LAN Connection
● USB 2.0 Port for Windows Connect Now
WiMAX VoIP Router
DIR-461
● Mobile Broadband Connection for
Workgroups
● Dual Dipole Antennas to Boost Signal
Strength
● Integrated 802.11g Wireless LAN
● Built-in 4-Port Ethernet Switch for Wired
LAN Connection
● USB 2.0 Port for Windows Connect Now
WiMAX Router
DIR-610
● Mobile Broadband Connection for
Notebook PC
● Dual Dipole Antennas to Boost Signal
Strength
● Supports Windows
WiMAX CardBus Adapter
DWM-110
● Mobile Broadband Connection for
Notebook and Desktop PC
● Multiple Embedded Antennas to Boost
Signal Strength
● Supports Windows
WiMAX USB Adapter
* Speed depends on 3G or 3.5G card and operator’s offering.
