D-Link Product Guide 2008
LAN SWITCHES
Features & Benefits
D-Link Product Guide 2008
ENTRy-LEVEL SNMP
ethernet SwitcheS
● Affordable Enterprise Features
» Include IP-MAC-port binding user
access screening, traffic segmentation,
802.1Q VLANs, 802.1x port-based/
MAC-based access control, external
RADIUS server authentication support.
» 802.1D Spanning Tree/802.1w Rapid
Spanning Tree, STP loopback detection
and broadcast storm control for network
resilience.
» 802.3ad Link Aggregation port trunks for
switch cascading and server link.
● Complete Set of Access
Control List (ACL)
(for DES-3028, 3028P, 3052, 3052P only)
» Up to 256 profiles, 256 centralized rules
for individual switch ports or range of
ports.
» ACL rules can be based on switch port,
VLAN ID, 802.1p Priority Queues, MAC
address, IPv4 address, DSCP, protocol
type, TCP/UDP port, user-defined
packet content and time-based ACL.
● CPU Interface Filtering
» Filters out vicious packets in internal
network and prevents them from
reaching and overwhelming switch’s
CPU.
● Quality of Service
» Multi-level packet classification based
on 802.1p Priority Queues, TOS, DSCP
and MAC addresses.
● Bandwidth Control
» Fine granularity to define limits down to
64Kbps segments for each port.
» When applied to control of broadcast
storms infected with virus, can limit
level of damage a virus attack can do to
network.
» IGMP snooping to control multicast
transmission.
» Port mirroring to facilitate diagnostics.
● DHCP Auto-Configuration
» Network administrators can pre-set
configurations and save them in TFTP
server.
» Individual switches can boot their
IP from server and load in pre-set
configurations.
● Single IP Management
» Multiple switch units can be managed
as a single object (a virtual stack), all
units identified by a single IP address.
» Network administrators can see Tree
View of members of the virtual stack
and network topology showing locations
of the units and their link information.
These managed Layer 2 Ethernet switches provide an entry-level SNMP
management solution for businesses. Workgroups looking for an advanced yet
affordable solution can deploy these switches to bring managed Ethernet connection
to their desktops.
These switches include more advanced software features than similar devices of
the same class. These features allow administrators to set up a secure network and
fine-tune the workgroup performance. For inter-workgroup connection, the switches
provide fiber uplinks to connect together groups of users in, for example, different
classrooms or departments spread across on a campus or between buildings.
Supporting D-Link’s Single IP Management, these switches can be easily configured
with any switches supporting D-Link’s Single IP Management, including the xStack
core switches, for integration with a more comprehensive network structured with
backbone and centralized high-speed servers.
DES-3010F
● 8 10/100BASE-TX Ports
● 1 100BASE-FX Port (SC Connector,
2 km Multi-Mode Fiber Transmission
Distance)
● 1 10/100/1000BASE-T Gigabit Port
● 5.6Gbps Switch Capacity
8-Port L2 Ethernet Switch
DES-3010G
● 8 10/100BASE-TX Ports
● 1 10/100/1000BASE-T Gigabit Port
● 1 SFP Slot for Fiber Gigabit
● 5.6Gbps Switch Capacity
8-Port L2 Ethernet Switch
DES-3016
● 16 10/100BASE-TX Ports
● 3.2Gbps Switch Capacity
16-Port L2 Ethernet Switch
DES-3010FL
● 8 10/100BASE-TX Ports
● 1 100BASE-FX Port (SC Connector,
30 km Single-Mode Fiber
Transmission Distance)
● 1 10/100/1000BASE-T Gigabit Port
● 5.6Gbps Switch Capacity
8-Port L2 Ethernet Switch
DES-3018
● 16 10/100BASE-TX Ports
● 2 Open Slots for Optional Fiber Ethernet
or Gigabit Uplinks
● 7.2Gbps Switch Capacity
DES-3052
48-Port L2 Ethernet Switch 16-Port L2 Ethernet Switch
● 48 10/100BASE-TX Ports
● 2 Combo 10/100/1000BASE-T/SFP
● 2 10/100/1000BASE-T Gigabit Ports
● 17.6Gbps Switch Capacity
DES-3026
● 24 10/100BASE-TX Ports
● 2 Open Slots for Optional Fiber Ethernet
or Gigabit Uplinks
● 8.8Gbps Switch Capacity
24-Port L2 Ethernet Switch
● 48 802.3af PoE 10/100BASE-TX Ports
● 2 Combo 10/100/1000BASE-T/SFP
● 2 10/100/1000BASE-T Gigabit Ports
● 17.6Gbps Switch Capacity
DES-3028
● 24 10/100BASE-TX Ports
● 2 Combo 10/100/1000BASE-T/SFP
● 2 10/100/1000BASE-T Gigabit Ports
● 12.8Gbps Switch Capacity
24-Port L2 Ethernet Switch
DES-3052P
48-Port L2 PoE Ethernet Switch
DEM-301T
● 1 10/100/1000BASE-T Gigabit Port
● For use with DES-3018 & DES-3026
Switches
1-Port 10/100/1000Mbps Module
DEM-301G
● 1 SFP Slot
● For use with DES-3018 & DES-3026
Switches
1-Slot SFP Module
DEM-201F
● 1 100BASE-FX Port (SC Connector)
● 2 km Multi-Mode Fiber Transmission
Distance
● For use with DES-3018 & DES-3026
Switches
1-Port 100BASE-FX Module
DES-3028P
● 24 802.3af PoE 10/100BASE-TX Ports
● 2 Combo 10/100/1000BASE-T/SFP
● 2 10/100/1000BASE-T Gigabit Ports
● 12.8Gbps Switch Capacity
24-Port L2 PoE Ethernet Switch
DEM-201FL
● 1 100BASE-FX Port (SC Connector)
● 15 km Single-Mode Fiber Transmission
Distance
● For use with DES-3018 & DES-3026
Switches
1-Port 100BASE-FX Module
