D-Link Product Guide 2008
EthErnEt AdAptErs
More than just for simple network interface, D-Link Ethernet adapters are designed
for the workstations to operate in a secure network environment. They provide many
software functions to make workstations an integrated part of a managed network.
The Ethernet server adapters provide the necessary bandwidth for server deployment
for fast access by workstations. These adapters provide multiple ports with port trunk
supporting load balancing and backup links for mission critical applications with
redundancy that maximizes network uptime.
● Full/Half Duplex Operation
● 802.3x Flow Control in Full-
Duplex
● ACPI Wake-On-LAN Power
Management
● Optional Remote Boot
Function
DFE-550TX
Advanced Ethernet PCI Adapter
DFE-538TX
● 10/100BASE-TX Port
● ACPI Wake-On-LAN Power
Management
● 802.3x Flow Control Full-Duplex Mode
Support
● Socket for Optional Remote Boot ROM
● Supports Windows, NetWare, IBM
LAN, FTP PC/TCP, SCO Open, Linux
Ethernet PCI Adapter
● 10/100BASE-TX Port
● ACPI Wake-On-LAN Power
Management
● IP Multicast
● 802.1Q VLAN, 802.1p Priority Queues
● SNMP Support
● Desktop Management Interface (DMI)
Driver Provided
● Socket for Optional Remote Boot ROM
● Supports Windows, NetWare, IBM
LAN, Sun PC-NFS, FTP PC/TCP, SCO
OpenServer, NCSA, Linux
DFE-530TX
Ethernet PCI Adapter
DFE-528TX
● 10/100BASE-TX Port
● Supports Windows, NetWare, Unix,
Mac OS
Ethernet PCI Adapter
● 10/100BASE-TX Port
● ACPI Wake-On-LAN Power
Management
● 802.1x Port-Based Authentication
● Socket for Optional Remote Boot ROM
● Supports Windows, NetWare, IBM
LAN, Sun PC-NFS, FTP PC/TCP,
Linux
DFE-530TX+
Ethernet PCI Adapter
● 10/100BASE-TX Port
● ACPI Wake-On-LAN Power
Management
● Socket for Optional Remote Boot ROM
● Supports Windows, NetWare, Linux,
Mac OS, Packet Driver, NDIS Driver
DFE-580TX
● 4 10/100BASE-TX Ports
● 800Mbps Server-to-Switch Port Trunk
● Per-Port Load Balance/Fault Tolerance
● Dynamic Fail Over Function in Backup
Mode
● 802.1p Priority Queues
● Supports in Windows, Linux
4-Port Ethernet Server PCI
Adapter
DFE-551FX
● 100BASE-FX SC Port
● Up to 2 km Multi-Mode Fiber Cable
Distance
● ACPI Wake-On-LAN Power Management
● 802.1Q VLAN, 802.1P Priority Queues
● Socket for Optional Remote Boot ROM
● Supports Windows, Mac OS, NetWare,
Linux
Fiber Ethernet PCI Adapter
DFE-530+R
● For Use with DFE-530TX+ Ethernet PCI
Adapter vFX
RPL Boot ROM
DFE-690TXD
● 10/100BASE-TX Port
● 32-bit CardBus Interface to PC Host
● Supports Windows, NetWare, NCSA,
Linux
Ethernet CardBus Adapter
DFE-551R
● For Use with DFE-551FX Ethernet PCI
Adapter
RPL Boot ROM
REmOTE BOOT ROm
The remote boot ROM are optional chips that can be plugged onto the adapters for
remote boot from boot servers. This function allows users to deploy the Ethernet adapters
in diskless workstations and configure them with access security. Diskless workstations
are useful for deployment at public network sites such as schools and libraries. These
workstations cannot boot by themselves; users need to key in their passwords to remote
boot up the system from a boot server.
DFE-530+P
● For Use with DFE-530TX+ Ethernet PCI
Adapter vFX
PXE Boot ROM
DFE-551P
● For Use with DFE-551FX Ethernet PCI
Adapter
PXE Boot ROM
DFE-534R3
● For Use with DFE-530TX Ethernet PCI
Adapter
RPL Boot ROM
DFE-554C
● For Use with DFE-550TX Ethernet PCI
Adapter vC3
RPL Boot ROM
DFE-534P3
● For Use with DFE-530TX Ethernet PCI
Adapter
PXE Boot ROM
DFE-554CP
● For Use with DFE-550TX Ethernet PCI
Adapter vC3
PXE Boot ROM
DFE-538R
● For Use with DFE-538TX Ethernet PCI
Adapter vF1
RPL Boot ROM
DGE-528R
● For Use with DGE-528T Gigabit PCI
Adapter
RPL/PXE Boot ROM
DFE-538P
● For Use with DFE-538TX Ethernet PCI
Adapter vF1
PXE Boot ROM
DFE-538P
● For Use with DFE-538TX Ethernet PCI
Adapter vF1
PXE Boot ROM
