D-Link Product Guide 2008
BROADBAND
Features & Benefits
D-Link Product Guide 2008
DEV-3418DC
● Same as DEV-3418 but with DC Input
Power
VDSL2 16-Port Switch
DEV-3718I
● 5-Band DMT-Based Ethernet over DSL
● 16 VDSL2 Ports
● 16 POTS Splitters
● 2 Combo 10/100/1000BASE-T/SFP Ports
● 10/100BASE-TX Management Port
● 10/100BASE-TX Alarm Port
● Software Functions Same as
DEV-3710I
VDSL2 16-Port Switch
DEV-3426
● 4-Band DMT-Based Ethernet over DSL
● 24 VDSL2 Ports
● 24 POTS Splitters
● 2 Combo 10/100/1000BASE-T/SFP Ports
● 10/100BASE-TX Management Port
● 10/100BASE-TX Alarm Port
● Software Functions Same as DEV-3418
VDSL2 24-Port Switch
DEV-3726I
● 5-Band DMT-Based Ethernet over DSL
● 24 VDSL2 Ports
● 24 POTS Splitters
● 2 Combo 10/100/1000BASE-T/SFP Ports
● 10/100BASE-TX Management Port
● 10/100BASE-TX Alarm Port
● Software Functions Same as DEV-3710I
VDSL2 24-Port Switch
VDSL2 MoDEMS,
RoUTERS & SWITCHES
● Upgrade to VDSL1 Standard
» VDSL2 outperforms VDSL in speed
and phone line distance from central
office (CO) switch to consumer premise
equipment (CPE) modem or router.
» Ideal for voice, video, data, high
definition television (HDTV) and
interactive gaming over the Internet.
● High Performance at Longer
Distance
» Maximum theoretical speed of 250Mbps
at “source”.
» Speeds of 25Mbps available to most
consumers.
» Speed of 100Mbps available on short
loops (up to 300 m phone line distance).
» Speed decreases as phone line
distance increases from 1 km.
● Interoperable With Existing
Carrier DSL Equipment
» Easy upgrade to systems already
installed over the last decade
● Up to Symmetric 100Mbps
Downstream/50Mbps Upstream
at Shortened Loop Lengths
» Allows operators to offer “super triple
play” of video, Internet and voice
services to compete with services
offered by satellite and cable operators.
» Ideal for HDTV, VoIP and video
conferencing.
» Not limited to short loops or MTU
(Multi-Tenant Units office buildings)/
MDU (Multi-Dwelling Units apartment
buildings and condominiums)
applications; can also be used for
medium range applications.
VDSL2 (Very-High-Bit-Rate Digital Subscriber Line 2) is an ITU-T G.993.2 standard an
access technology that exploits the existing infrastructure of telephone copper wires
that are present in very home, office building, factory, and public premise. VDSL2 can
be deployed from the telephone company and service provider central offices, from
fiber-fed cabinets located near the customer premises, or within buildings.
VDSL2 is the newest and most advanced standard of DSL broadband wire line
communications. Designed to support the wide deployment of services such as voice,
video, data, high definition television (HDTV) and interactive gaming, VDSL2 enables
operators and carriers to gradually, flexibly, and cost efficiently upgrade existing DSL
infrastructure.
VDSL2 is an enhancement to G.993.1 VDSL that permits the transmission of
asymmetric and symmetric (full-duplex) aggregate data rates many times higher on
the twisted-pair phone wires using a bandwidth up to 30MHz.
DSL-5540C
● 4-Band DMT-Based Ethernet over DSL
● 1 VDSL 2 Port
● Built-in POTS Splitter
● 1 Analog Phone (POTS) Port
● 4 10/100BASE-TX Ethernet LAN Ports
VDSL2 4-Port Modem
DSL-6540I
● 5-Band DMT-Based Ethernet over DSL
● 1 VDSL2 Port
● Built-in POTS Splitter
● 4 10/100BASE-TX Ethernet LAN Ports
● NAT, DHCP Server, IP Multicast
● MAC/IP/Port Filtering, DoS/DDoS
Firewall
VDSL2 4-Port Router
DVA-6541i
● 6-Band VDSL
● 1 VDSL2 Port
● 4 10/100BASE-TX Ethernet LAN
Ports
● 1 USB Printer Port
● NAT, DHCP Server, IP Multicast
● QoS Priority Queues
● SPI, DoS Firewall
VDSL2 4-Port Route
DSL-6640I
● Same as DSL-6540I but with
Integrated 802.11g Wireless LAN
VDSL2 Wireless G Router
DEV-3426DC
● Same as DEV-3426 but with DC Input
Power
VDSL2 24-Port Switch
DEV-3710I
● 5-Band DMT-Based Ethernet over DSL
● 8 VDSL2 Ports
● 8 POTS Splitters
● 2 Combo 10/100/1000BASE-T/SFP Ports
● 10/100BASE-TX Management Port
● 10/100BASE-TX Alarm Port
● IGMP, Multicast, VLAN, 802.1p QoS,
Traffic Segmentation, Spanning Tree
● VLAN/MAC/IP-Based Filter
● MAC/IP-Based ACL
● Link Aggregation
VDSL2 8-Port Switch
DEV-3418
● 4-Band DMT-Based Ethernet over DSL
● 16 VDSL2 Ports
● 16 POTS Splitters
● 2 Combo 10/100/1000BASE-T/SFP Ports
● 10/100BASE-TX Management Port
● 10/100BASE-TX Alarm Port
● IGMP, Multicast, VLAN, 802.1p QoS,
Traffic Segmentation, Spanning Tree
● VLAN/MAC/IP-Based Filter
● MAC/IP-Based ACL
● Link Aggregation
VDSL2 16-Port Switch
