D-Link Product Guide 2008
WIRELESS
NETWORKING
Features & Benefits
D-Link Product Guide 2008
WIRElESS 108 AG
The Wireless 108AG employs both the 5GHz and 2.4GHz frequencies, incorporating
802.11a, 802.11b and 802.11g wireless LAN standards to make it compatible with
virtually all existing 802.11 networks. This wireless LAN series provides the most
expanded user bandwidth available in a wireless device. It offers data transfer rates
of up to 108Mbps in the Turbo Mode in either the 2.4GHz or 5GHz bands when
operating with other D-Link Wireless 108AG products, and in the 2.4GHz band when
operating with other D-Link Wireless 108G products. 1 Hundreds of wireless clients
can connect to this network, using any one of its non-overlapping channels.
Through the user access control function in wireless routers and access points,
network administrators can segment users on the wireless network by frequency
band. Users who require special networking privilege access to sensitive company
data, video conferencing, or connectivity to specific departments may, for example,
use the 802.11a channels, while other employees may use the 802.11b and 802.11g
channels. This type of user segmentation optimizes the performance of the routers
and access points, and delivers the best network experience to each set of users.
DWl-AG132
● 2.4GHz and 5GHz Dual Band Operation
● USB Connection with USB Extension
Cable & Cradle Provided
● Supports Windows OS
Wireless 108AG USB Adapter
DWl-AG530
● 2.4GHz and 5GHz Dual Band Wireless
Connection for Desktop PC
● Supports Windows, Linux
Wireless 108AG PCI Adapter
● Dual-band operation
» Simultaneous operation in 802.11b/g
2.4GHz and 802.11a 5GHz frequency
bands.
» More wireless bandwidth available for
use.
» Network can be segmented according to
frequency band.
● Up to 108Mbps Data Transfer
rate
» 108Mbps Turbo mode wireless speed
when operating with other 108G or
108AG devices.
» High bandwidth for wireless transfer
of Internet surfing, file download,
multimedia, voice and video.
● 64/128/152-Bit WEP Data
Encryption
» Protection of wireless data traveling in
the air that are sent by users.
● WPA EAP/PSK, WPA2 EAP/PSK
With TKIP, AES Support
» Wireless LAN security including data
encryption keys and user authentication
for network access.
» Keeps out intruders located next door,
upstairs or downstairs.
» Advanced encryption and security
schemes for business environments.
● WPS Certified
» Wi-Fi Protected Security (WPS)
provides easy security setup for wireless
clients from an AP or router. The AP
and routers provide a WPS click button
from a PC screen and a WPS push
buttons from the devices themselves to
let administrators broadcast settings to
clients, eliminating the need for clients
to manually key in encryption keys
and settings to establish connection to
network.
DWl-AG660
● 2.4GHz and 5GHz Dual Band
Wireless Connection for Notebook/
Laptop PC
● Supports Windows, Linux
Wireless 108AG CardBus Adapter
DI-784
● 2.4GHz and 5GHz Dual Band
Operation
● DoS Prevention, SPI, Intrusion
Detection, Event Log
● MAC-Based Access Control
● Domain/URL Filtering Parental Control
● 4 10/100BASE-TX Ethernet LAN Ports
Wireless 108AG 4-Port Router
DWl-7100AP
● 2.4GHz and 5GHz Dual Band Operation
● Operable in AP, WDS, WDS With AP, or
Repeater Mode 2
● WLAN STA Partitioning
● SNMP Manageable
● Indoors Use
DWl-7700AP
Wireless AG Outdoors Access Point Wireless 108AG Access Point
● 2.4GHz and 5GHz Dual Band Operation
(Up to 54Mbps)
● Dual 5dBi Gain Antennas
● 802.3af Power Over Ethernet (PoE) (PoE
Base Unit Provided)
● Plenum-Rated Housing
● Operable in AP, WDS or WDS With AP
Mode
● Multiple SSID, 802.1Q VLAN, WLAN STA
Partitioning
● SNMP Manageable
DWl-8200AP
● 2.4GHz and 5GHz Dual Band Operation
● Plenum-Rated Housing
● Dual 10/100BASE-TX Ethernet Ports
(One Port With 802.3af PoE)
● Dual Ethernet Ports With Separate SSID
Can Simultaneously Connect to Wired
Network
● Dual 5dBi Gain Antennas
● 802.1Q VLAN
● Operable in AP, WDS or WDS With AP
Mode
● SNMP Management Through D-View
● Indoors Use
Wireless 108AG Access Point
1 108Mbps Turbo mode operation on 5GHz frequency
band not allowed in EU countries.
2 WDS and repeater modes on 5GHz frequency band
not allowed in EU countries.
