DPN-540
● 1 10/100/1000BASE-T PON Port
● 4 10/100/100BASE-TX Ports
● 1 Video Port (to TV)
GE PON ONU
DPN-2016
● 17-Slot Chassis-Based OLT
● Up to 16 1000BASE-LX PON Ports (SC
Connectors)
● Up to 16 Combo 10/100/1000BASE-T/
SFP Ports
● 1 Control Module Card
● 1 Power Supply Module
● PON Ports Support Up to 10 or 20 km
Single-Mode Fiber Cable Lengths
GE PON OLT
DPN-2016P
● Redundant Power Supply for DPN-
2016
Power Supply
DPN-2016C
● Control Module for DPN-2016
● RJ-45 In-Band Ports
● RS-232 CLI Out-of-Band Port
● SNMP, D-View, Telnet Support
Control Card
DPN-3012
● 8 1000BASE-LX PON Ports (SFF SC
Connectors)
● 4 Combo 10/100/1000BASE-T/SFP Ports
● PON Port Supports Up to 20 km Single-
Mode Fiber Cable Length
● RJ-45 and RS-232 Console Ports
GE PON Switch
GE PoN
● Cost Saving Solution for
Service Providers
» Multiple SFF or SC Gigabit PON ports
» Multiple Ethernet or combo Gigabit
10/100/1000BASE-T/SFP end-user
ports
» SFF or SC 802.3ah Standard OLT
Downlink Ports
» Each OLT port can support up to 32
ONU
» Up to 1.25Gbps between OLT and ONU
» OTL ports can support up to 20km fiber
cable lengths
● Flexible/Secure Configuration/
Management
» Local RS-232 out-of-band CLI
» Remote in-band SNMP/Telnet support
» SNMP, MIB interface and D-View
network management system support
» Firmware upgrade via FTP or TFTP
● Redundancy
» Chassis solution supports line card,
control card, power supply hot swap
capability
» Switch solution supports Dual
Configuration
● Advanced Functions for GE-
PoN Service offering
» OAM remote loopback test
» 802.1D Bridge function
» Up to 2000 MAC addresses for each
PON interface
» 802.1Q VLAN security/traffic
segmentation
» QoS with multiple 802.1p-based priority
levels
» TOS to CoS
» Rate Limiting capability
» IGMP v2
» ICMP
» Dual Configuration support (for GE PON
switches)
Gigabit Ethernet Passive Optical Network (GE PON) devices deliver high-speed
voice, data and video services to residential and business subscribers. They present
a high-speed, Fiber-To-The-Home/Building (FTTH/FTTB) and extremely cost-
effective alternative to conventional access equipment, reducing points of failure and
simplifying network architecture.
D-Link’s PON consists of central office nodes, called an optical line terminal (OLT),
user nodes, called optical network units (ONU). Between them are the fibers and
splitters. The ONU terminate the PON and provide Ethernet interfaces to the end-
users. The OLT provide the interface between the PON and the backbone network.
They complete the end-to-end last mile with up to 1Gbps of bandwidth to residential
and business customers.
D-Link’s PON switches provide Point to Multi-Point connection from the Central
Office’s (CO) Optical Line Terminal (OLT) with single strand fibers going out to
passive optical splitters where signal are multiplied to different lines. Combining
the economic benefits of Gigabit Ethernet Optical Network (GE PON) with built-in
switching functionalities, these devices provide the platform for bandwidth-intensive,
high margin applications including Internet TV, HDTV, voice and gaming
The GE-PON service delivers up to 1Gbps speed over optical fiber wiring. The OLT
convert GE-PON different interfaces to trunk interfaces. Each OLT can provide multiple
10/100/1000BASE-T/SFP combo interfaces as trunk interfaces, and supports L2
switch function. Each GE-PON interface can accommodates up to 32 ONU through
the optical splitter.
DPN-204
● 1 1000BASE-LX PON Port (SC
Connector)
● 4 10/100BASE-TX Ports
● PON Port Supports Up to 10 km Single-
Mode Fiber Cable Length
GE PON ONU
DPN-204L
● 1 1000BASE-LX PON Port (SC
Connector)
● 4 10/100BASE-TX Ports
● PON Port Supports Up to 2 km Single-
Mode Fiber Cable Length
GE PON ONU
DPN-301
● 1 1000BASE-LX PON Port (SC
Connector)
● 1 10/100/1000BASE-T Port
● PON Port Supports Up to 10 km
Single-Mode Fiber Cable Length
GE PON ONU
DPN-301L
● 1 1000BASE-LX PON Port (SC
Connector)
● 1 10/100/1000BASE-T Port
● PON Port Supports Up to 20 km Single-
Mode Fiber Cable Length
GE PON ONU
DPN-2016M
● Line Card for DPN-2016
● 1 1000BASE-LX PON Port (SC
Connector)
● 1 Combo 10/100/1000BASE-T/SFP Port
● PON Port Supports Up to 10 or 20 km
Single-Mode Fiber Cable Length
Line Card
