Delfield 406-CA - Manual

Project __________________________________
Item ____________________________________
Quantity ________________________________
CSI Section 11400
Approved _______________________________
Date ____________________________________
980 S. Isabella Rd.
Mt. Pleasant, Michigan 48858
Phone: 800-733-8948 or 989-773-7981
Fax: 800-669-0619
www.delfield.com
Specifications
Standard Features Options &
Accessories
Features Delfield’s exclusive ABS interior.
ABS is extremely durable - it won’t dent,
chip or corrode and is backed by a
limited lifetime warranty
Stainless steel front and sides
Two epoxy coated wire shelves, standard
per unit
Environmentally friendly R404A
refrigerant
Foamed in place environmentally
friendly, Kyoto Protocol Compliant,
Non ODP (Ozone Depletion Potential),
Non GWP (Global Warming Potential)
polyurethane cuts energy costs
Black recessed quick grip handle
Rugged 6” high heavy duty metal legs
(models 406 & 407 only). Units with a
“CA” suffix are standard on 3” diameter
(3.75” ride height) casters
All units come standard hinged right
and may be changed at the factory at no
charge. Indicate when order is placed
7’ cord and plug supplied
•
•
•
•
•
•
•
•
•
406 Undercounter refrigerator
single section on legs
406-CA Undercounter refrigerator
single section on casters
407 Undercounter freezer
single section on legs
407-CA Undercounter freezer
single section on casters
Models
406 & 407 Undercounter Series
40
6 &
4
07
U
nd
erc
ou
nte
r S
eri
es
Stainless steel back
Plastic laminate on front
Additional shelf
Stainless steel single-tier
overshelf
3” diameter (3.75” ride height)
casters
Model 409 stacking collar
Door lock
220 volt, 50 Hertz electrical
system
•
•
•
•
•
•
•
•
Model 406-CA
Exterior bottom shall be heavy-gauge galvanized metal.
Exterior ends shall be heavy-gauge stainless steel.
Base interior shall be one-piece thermoformed ABS plastic
material, with integral shelf supports. ABS interior is
backed by a limited lifetime warranty. Base shall be fully
insulated with high-density foamed-in-place environmentally
friendly, Kyoto Protocol Compliant, Non ODP (Ozone
Depletion Potential), Non GWP (Global Warming Potential)
polyurethane.
Door shall have a heavy-gauge stainless steel exterior,
with a thermoformed ABS plastic interior liner, and shall be
fully insulated with foamed-in-place polyurethane. Door
handle shall be black, recessed ABS. Cabinet shall have (2)
adjustable epoxy-coated wire shelves installed.
MODELS 406/406-CA REFRIGERATORS REFRIGERATION
SYSTEM
Refrigeration system shall use HFC-404A refrigerant.
Compressor shall be 1/5 h.p., with condenser coil and hot
gas condensate evaporator mounted on rear of cabinet.
Evaporator coil and temperature control shall be mounted on
the interior rear wall of the cabinet. Refrigerant flow shall be
controlled by a capillary tube. Cabinet shall maintain 36°F to
40°F (2°C to 4°C) interior cabinet temperature.
MODELS 407/407-CA FREEZERS REFRIGERATION SYSTEM
Freezer system shall use HFC-404A refrigerant. Compressor
shall be 1/5 h.p., with condenser coil and hot gas condensate
evaporator mounted on rear of cabinet. Evaporator coil and
temperature control shall be mounted on the interior rear
wall of the cabinet. Refrigerant flow shall be controlled by a
capillary tube. Cabinet shall maintain -5°F to 0°F
(-21°C to -18°C) interior cabinet temperature.
Electrical connections shall be 115 volt, 60 Hertz, single
phase. Unit shall have a 7’ (2.1m) long electrical cord and
NEMA 5-15P plug. Cord and plug shall be located on rear of
cabinet, 16” (40.6cm) above floor, 5” from the left side.
406/407
Equipment is shipped with loose 6” (15.2cm) high metal legs
with black enamel finish unless mounting is specified on
original sales order. Exterior top shall be one-piece, heavy-
gauge stainless steel with front edge turned down to form
nosing and rear edge turned down.
406-CA/407-CA
Equipment is shipped with loose 3” diameter (3.75” ride
height) casters high casters (two locking and two non-
locking) unless mounting is specified on original sales order.
Exterior top shall be one-piece, heavy-gauge aluminum with
all edges turned down.
