Radial Winch
35.2 ST
Installation and Maintenance Manual
RadialWinch35.2STCW
C=drum in chromed bronze - W=components RAL 9003
*Servicekitavailable;seewinchkitsectiononthewebsitewww.harken.com
**Winchproductsticker
Pos.
Q.ty Code
Description
1
1
A 941310 00
Assy Base W35
Base W35
Heli-coil M6x9
Roller Ø6x19
Bushing Ø22xØ25x9.5*
Bushing Ø9xØ11x12*
Bushing Ø12xØ14x11*
2
1
A 941314 00 W
Assy Skirt W35 RAL 9003
Skirt W35 RAL 9003
Winch Product Sticker**
3
1
S 41302 00 04
Gear Z12
4
1
S 41303 00 04
Pawls Carrier Ø8xN2
5
4
S 00008 00 03
Pawl Ø8
6
4
S 00038 00 01
Pawl Spring Ø8
7
1
S 41283 00 41
Gear Z23
8
1
S 41300 00 04
Pin ø9x55
9
1
S279090002
Washer 36x9,5x1*
10
1
S 41565 00 04
Rachet Gear Z18
11
1
S 41285 00 41
Pinion Z13
12
1
S 41312 00 02
Washer Ø22.5xØ45x1*
13
1
S 41307 00 04
Pin Ø9-Ø12x32.5
14
1
A94130500
Assy Gear Z20
Gear Z20
Bushing Ø12xØ14x8*
15
1
A94131100
Assy Housing W35
Housing W35
Bushing Ø9xØ11x7*
Heli-coil M6x9
Bushing Ø22xØ25x8.5*
Pos.
Q.ty Code
Description
16
6
M0635103
Socket head screw M6x16 UNI 5931*
17
1
S 41315 00 82
Washer Ø62xØ80x1.5*
18
2
A74136000
Bearing Ø56xØ68x24*
19
1
A94139000
Assy Central Shaft W35
Central shaft W35 ST
Washer Ø17.2xØ32x1.5
20
1
S 41876 00 63
Winch Serial Number Sticker
21
1
S 41294 00 A0
Stripper arm support
22
1
S413170043
Drum W35 C
23
1
S 28168 00 97
Red line*
24
1
A 941318 00 W
Assy Winch 35 Jaws RAL 9003
Lower Jaw W35 RAL 9003
Upper Jaw W35 RAL 9003
Peeler W35 RAL 9003
Spring
25
4
M0601803
Screw UNI EN ISO 1207:1996 - M6x35
- A4*
26
1
S 41420 00 19
Stripper Arm W35
27
3
M6007103
Screw M6x50 UNI6107*
28
1
A94136400
Assy Socket W35
Socket Handle W35
Washer Ø7.7xØ25x5.8
Screw M8x20 UNI 6109*
29
1
S 41295 00 A5 W Cover 2 speed W35 RAL 9003
