Radial Winch
35.2 PT
Installation and Maintenance Manual
*Service kit available; see winch kit section on the website www.harken.com
**Winch product sticker
Parts list
Radial Winch 35.2 PTA
A= drum in anodised aluminium
Pos.
Q.ty
Code
Description
1
1
A 941310 00
Assy Base Winch 35
Winch Serial Number Sticker
2
1
A 941314 00
Assy Skirt Winch 35**
3
1
S 41302 00 04
Gear Z12
4
1
S 41303 00 04
Pawls Carrier Ø8xN2
5
4
S 00008 00 03
Pawl Ø8*
6
4
S 00038 00 01
Pawl Spring Ø8*
7
1
S 41283 00 41
Gear Z23
8
1
S 41300 00 04
Pin ø9x55
9
1
S279090002
Washer 36x9,5x1*
10
1
S 41565 00 04
Rachet Gear Z18
11
1
S 41285 00 41
Pinion Z13
12
1
S 41312 00 02
Washer Ø22.5xØ45x1*
13
1
S 41307 00 04
Pin ø9-ø12x32.5
14
1
A94130500
Assy Gear Z20
15
1
A94131100
Assy Housing Winch 35
16
6
M0635103
Socket head screw M6x16 UNI 5931*
17
1
S 41315 00 82
Washer Ø62xØ80x1.5*
18
2
A74136000
Bearing Ø56xØ68x24*
19
1
A94151900
Assy Central Shaft W35
20
1
S 41876 00 63
Winch Serial Number Sticker
21
1
S 41514 00 A0
Socket Support PT
22
1
S 41316 00 53
Drum W35
23
1
S 28168 00 97
Red line
24
1
S 41515 00 53
Plain Top W35/40
25
4
M0619580
Ball 3/16"
26
4
M 06037 03
Screw M6x12 UNI 5931
27
1
S 41516 00 53
Cover W35 PT
28
1
S 41522 00 80
PT spacer
29
3
M0600903
Screw M6x20 UNI5931
30
1
A94136400
Assy Socket W20-80
Screw M8x20 UNI 6109*
Washer Ø7.7xØ25x5.8*
Socket Handle W20/80*
