Program Settings
B
#
Parameter
Input Type
Range of Values
Default Value
Hood Controller Parameters
HCxx‐01 Hood Network Address
Single Select List 0 To 39
1
HCxx‐02 Name
Text Field Input Up to 20 Characters
HC‐x
HCxx‐03 Optic Sensor
Single Select List Yes or No
Yes
HCxx‐04 Temp Channel 1
Single Select List No, Hood, Auto Only, Supply, Space
Hood
HCxx‐05 Temp Channel 1 Span Max. (°F)
Single Select List 50F To 200F (Increments Of 5F)
90
HCxx‐06 Temp Channel 2
Single Select List No, Hood, Auto Only, Supply, Space
No
HCxx‐07 Temp Channel 2 Span Max. (°F)
Single Select List 50F To 200F (Increments Of 5F), Match Channel 1 Match Channel 1
HCxx‐08 Temp Channel 3
Single Select List No, Hood, Auto Only, Supply, Space
No
HCxx‐09 Temp Channel 3 Span Max. (°F)
Single Select List 50F To 200F (Increments Of 5F), Match Channel 1 Match Channel 1
HCxx‐10 Temp Channel 4
Single Select List No, Hood, Auto Only, Supply, Space
No
HCxx‐11 Temp Channel 4 Span Max. (°F)
Single Select List 50F To 200F (Increments Of 5F), Match Channel 1 Match Channel 1
HCxx‐12 Temp Actual Channel 1
Enter Offset
User Inputs Actual Temperature 0 To 500F
Measured Temp
HCxx‐13 Temp Actual Channel 2
Enter Offset
User Inputs Actual Temperature 0 To 500F
Measured Temp
HCxx‐14 Temp Actual Channel 3
Enter Offset
User Inputs Actual Temperature 0 To 500F
Measured Temp
HCxx‐15 Temp Actual Channel 4
Enter Offset
User Inputs Actual Temperature 0 To 500F
Measured Temp
HCxx‐16 Temp Channel 1 Span Min. (°F)
Single Select List 50F to 90F (Increments of 1F)
75
HCxx‐17 Temp Channel 2 Span Min. (°F)
Single Select List 50F to 90F (Increments of 1F), Match Channel 1
Match Channel 1
HCxx‐18 Temp Channel 3 Span Min. (°F)
Single Select List 50F to 90F (Increments of 1F), Match Channel 1
Match Channel 1
HCxx‐19 Temp Channel 4 Span Min. (°F)
Single Select List 50F to 90F (Increments of 1F), Match Channel 1
Match Channel 1
HCxx‐20 Optic Smoke Density
Single Select List Low, Medium, or High
Medium
Exhaust Hood Parameters
EHxx‐01 Primary Exhaust ID
Single Select List 1 to 39
1
EHxx‐02 Name
Text Field Input Up To 20 Characters
Hood x
EHxx‐03 Minimum Speed
Single Select List 30% To 100%, Increments Of 5%
50%
EHxx‐04 Maximum Speed
Single Select List 30% To 100%, Increments Of 5%
100%
EHxx‐05 Select Hood Controllers
Multi‐Select List 0 to 39
None Selected
EHxx‐06 Temperature Sensor Node(s)
Multi‐Select List 00‐1 to 39‐4
EHxx‐07 Optic Sensor Node(s)
Multi‐Select List 00 to 39
EHxx‐08 Auto On Hood Temperature
Single Select List Not Used, Auto On 70F ‐ 120F
Auto On 120F
EHxx‐09 Auto On Space Differential
Single Select List Not Used, Room Difference +1F ‐ +40F
Not Used
EHxx‐10 Auto Off Hood Temp
Single Select List Not Used, Auto Off 65F ‐ 100F
Not Used
EHxx‐11 Auto Off Space Differential
Single Select List Not Used, Room Difference +1F ‐ +20F
Not Used
EHxx‐12 Auto On/Off Grouping
Single Select List Yes Or No
Yes
EHxx‐13 Digital Inputs To Utilize
Multi‐Select List DI 1, DI 2, DI 3
Select All
EHxx‐14 Digital Outputs To Affect
Multi‐Select List Relay 1, Relay 2, 24VDC 1, 24VDC 2
Select All
EHxx‐15 Temperature Alarm Auto On
Single Select List Not Used, System, 100F, 125F, 150F, 200F, 250F,
System
EHxx‐16 Short Cycle Ratio
Single Select List Not Used, 20%, 30%, 40%, 50%, 60%, 70%, 80%
Not Used
EHxx‐17 User Interface On/Off
Single Select List None, Touchpad 1‐10, Aux Touchpad 0‐9
GUI 1
EHxx‐18 Exhaust CFM
Integer Input
0 to 100,000
1000
EHxx‐19 Groups
Multi‐Select List 1‐10
"1" is Selected
EHxx‐20 Touchpad Display Node
Read Only
1‐10
1
EHxx‐21 Optic Hang time
Single Select List System, 5, 10, 15, 30, 45, 60, 120, 180, 300
System
