Install Air Purge Units
8
Remove the lids from each APU box to
prepare for step 7.
Attach an APU to each Purge Pipe and
tighten the compression fitting.
A
Attach APU to Purge Pipe
Remove APU lids
B
Optic Cable
Plug In Optic Cables
21
C
Plug the Optic Cables into either receptacle on the header board inside each APU.
