Page 24
Remove the Temperature Cable from its
package. Connect one end to the Tempera-
ture Sensor receptacle.
Plug Cable into
Temperature Sensor
Plug Into Hood Controller
Install Cables
(Temperature Sensor)
9
G
Melink Corporation (513) 965-7300 www.melinkcorp.com
H
Connect the other end of the cable into a Temp port on the Hood Controller. Make sure to note
which port each sensor is plugged into as they will be assigned via programming.
MELINK
Intelli-Hood
Controls
®
®
24
