Install cables – Greenheck Melink IH3 Installation User Manual
Page 25
VFD Ports
(1 &2)
Aux Device
Port
Plug Into Hood Controller
Install Cables
(Hood Controller)
9
J
Melink Corporation (513) 965-7300 www.melinkcorp.com
25
L
K
Secure APU Lid
...then replace the lid on the APU and
tighten the thumbscrew. Repeat steps A-D
for remaining hoods.
Hood Network
Ports
Ethernet Port
USB Port
When optics are being used, plug a cable in between each APU box and the Optic /APU Ports on
the Hood Controller...
