VoIP Telephones
Getting Started
Product Overview
Thank you for purchasing a GAI-Tronics Voice Over Internet Protocol (VoIP) telephone. The VoIP
Telephones are designed for connection to a 10/100 baseT Ethernet. These telephones will operate from
Power-over-Ethernet or an external power source. The VoIP Telephones provide direct point-to-point
communications between personnel throughout the facility over the existing LAN.
In addition to providing standard telephone operation, GAI-Tronics VoIP telephones feature real-time
alarm reporting that enables system supervisors to monitor the phones activity and address caller needs or
maintenance issues immediately. Also, four user configurable inputs and two outputs have been provided
for customer use. This manual applies to the following GAI-Tronics VoIP Telephones:
Model Description
293-700 VoIP Phone – This phone is housed in a safety yellow, glass-reinforced polyester
enclosure that is designed to be surface-mounted and includes an emergency push button.
293AL-700 VoIP Phone – The vandal-resistant phone is housed in a cast aluminum enclosure painted
safety yellow that is designed to be surface-mounted and includes an emergency push
button.
294AL-702 VoIP Phone with Keypad – A cast aluminum enclosure painted safety yellow that is
designed to be surface-mounted and includes a 12-button Braille keypad, an emergency
push button and a call (off-hook) button.
297-700 Flush-panel VoIP Phone – This is a flush-mount phone with a heavy-gauge brushed
stainless steel front panel, and includes an emergency autodial push button.
297-701 Flush-panel VoIP Phone – This is a flush-mount phone with a heavy-gauge brushed
stainless steel front panel, and includes an emergency autodial push button and a call (off-
hook) autodial button.
297-702 Flush-panel VoIP Phone – This is a flush-mount phone with a heavy-gauge brushed
stainless steel front panel, and includes two call (off-hook) autodial buttons.
297-703 Flush-panel VoIP Phone – This is a flush-mount phone with a heavy-gauge brushed
stainless steel front panel, and includes three call (off-hook) autodial buttons.
298-701 Flush-panel VoIP Phone with Keypad – This is a flush-mount phone with a heavy-gauge
brushed stainless steel front panel, and includes a 12-button Braille keypad and a call
(off-hook) autodial button.
298-702 Flush-panel Emergency Phone with Keypad – This flush-mount phone with a heavy-
gauge brushed stainless steel front panel includes a 12-button Braille keypad, an
emergency push button, and a call (off-hook) button.
