Integrated Peripherals
► OnChip ATA Devices/OnBoard Devices/SuperIO Configuration/USB Configuration
Press
OnChip ATA Devices
► SATA#1 Configuration
SATA#1 are the SATA ports 1, 2, 3, 4 of the motherboard. This item allows you select the
mode of the SATA ports. Setting values are: [Disabled], [Compatible], [Enhanced].
► Configure SATA#1 as
This item is used to set the operation mode of your SATA ports 1, 2, 3, 4. Setting values are:
[IDE]; [RAID]; [AHCI].
[IDe] - This configures the SATA ports to support IDE mode.
[RAID] - When you enable RAID, it means all your SATA drives must also support AHCI.
CMOS Setup Utility - Copyright (C) 1985-2008, American Megatrends, Inc.
