Foxconn G45MG User Manual
Page 13
1
6
6. RJ-45 lAN Port
The
Ethernet LAN port provides Internet connection at up to 10/100/1000Mb/s data rate.
7. 1394a Port
This port is used to connect a 1394a device.
Active
LED
Link
LED
LAN Type
Left: Active
Right: Link
Status
Description
Status
Description
1000M
Off
No Link
Off
No Link
Green
Blinking
Data Activ-
ity
Off
10 Mb/s Connection
Green
100 Mb/s Connection
Orange
1000 Mb/s Connection
