Reset Disks to Non-RAID
Reset RAID volume allows you to replace a failed disk with a new one, and the
operating system will rebuild the data later. For RAID0, reset a hard disk would totally
crash the system, but for RAID1, RAID10 and RAID5, they all can be rebuilt.
When rebuild is needed, you must first install a new hard disk in your system before
getting into Intel
®
Matrix Storage Manager utility, because the utility will ask you which
hard disk the new rebuild will be performed.
example 1. Reset a RAID0 system.
1. A TryRAID0 volume was built with two 232.9GB hard disks, we want to reset one of
them. Select “
3. Reset Disks to Non-RAID” in main menu and press
2. A warning message is displayed.
Intel(R) Matrix Storage Manager option ROM v5.0.0.1011 ICH9R wRAID5
Copyright(C) 2003-04 Intel Corporation All Rights Reserved.
1. Create RAID Volume
3. Reset Disks to Non-RAID
2. Delete RAID Volume
4. Exit
RAID Volume :
* = Data is Encrypted
ID
Name
Level Stripe Size
Status Bootable
0
TryRAID0
RAID0(Stripe) 128KB 465.8GB
Normal
Yes
Physical Disks:
Port Drive Model
Serial #
Size
Type/Status(Vol ID)
0
WDC WD2500JS-60N WD-WCANKC865380 232.9GB
Member Disk(0)
2
Maxtor 6L250S0
L50SKP4G
232.9GB
Member Disk(0)
4
ST3320620SV
9QF4YJGQ
298.1GB
Non-RAID Disk
5
ST3300831AS
3NF02XH2
279.5GB
Non-RAID Disk
[↑↓]-Select [ESC]-Exit [ENTER]-Select Menu
Intel(R) Matrix Storage Manager option ROM v8.5.0.1013 ICH10R wRAID5
Copyright(C) 2003-08 Intel Corporation. All Rights Reserved.
[
DISK/VOLUME INFORMATION
]
[
MAIN MENU
]
3. Reset Disks to Non-RAID
Intel(R) Matrix Storage Manager option ROM v5.0.0.1011 ICH9R wRAID5
Copyright(C) 2003-04 Intel Corporation All Rights Reserved.
1. Create RAID Volume
3. Reset Disks to Non-RAID
3. Delete RAID Volume
4. Exit
RAID Volume :
* = Data is Encrypted
ID
Name
Level Stripe Size
Status Bootable
0
TryRAID0
RAID0(Stripe) 128KB 465.8GB
Normal
Yes
Physical Disks:
Port Drive Model
Serial #
Size
Type/Status(Vol ID)
0
WDC WD2500JS-60N WD-WCANKC865380 232.9GB
Non-RAID Disk
2
Maxtor 6L250S0
L50SKP4G
232.9GB
Non-RAID Disk
4
ST3320620SV
9QF4YJGQ
298.1GB
Non-RAID Disk
5
ST3300831AS
3NF02XH2
279.5GB
Non-RAID Disk
[↑↓]-Select [ESC]-Exit [ENTER]-Select Menu
Intel(R) Matrix Storage Manager option ROM v8.5.0.1013 ICH10R wRAID5
Copyright(C) 2003-08 Intel Corporation. All Rights Reserved.
[
DISK/VOLUME INFORMATION
]
[
MAIN MENU
]
Resetting RAID disk will remove its RAID structures
and revert it to a non-RAID disk.
WARNING: Resetting a disk causes all data on the disk to be lost.
Port Drive Model
Serial #
Size
Status
0 WDC WD2500JS-60N WD-WCANKC865380 232.9GB
Member Disk
2 Maxtor 6L250S0
L50SKP4G
232.9GB
Member Disk
Select the disks that should be reset
[↑↓]-Previous/Next [SPACE]-Selects [ENTER]-Selection Complete
[
RESET RAID DATA
]
0 WDC WD2500JS-60N WD-WCANKC865380 232.9GB Member Disk
