2. Copy section 5-2, BIOS Configuration.
Shut down the computer, connect SATA hard disks to SATA ports, power on
computer again.
Press key, get into BIOS, set SATA mode to [RAID], press to save and
exit BIOS. PC will reboot.
3. Copy section 5-3, Create RAID in BIOS.
Press simultaneously to get into RAID BIOS set up (Intel ® Matrix
Storage Manager option ROM utility).
Configure your new hard disks to RAID0, 1, 5 or 10. Exit RAID BIOS. PC will reboot.
4. The Windows XP is running again and a new hardware of RAID disk was found.
Click [Cancel] to skip this Wizard.
Click to exit.
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
OnChip ATA Devices
Configure SATA#1 as [RAID] Help Item
Max Ports on SATA#1 [6 Ports]
JMicron 36x ATA Controller [Enabled]
IDE
RAID
AHCI
↑↓←→:Move Enter:Select +/-/:Value F10:Save ESC:Exit F1:General Help
F9:Optimized Defaults
[RAID]
Options
