► Keyboard

The system boot will not stop for a keyboard error if you enabled this item.

► Mouse

The system boot will not stop for a mouse error if you enabled this item.

► Floppy

The system boot will not stop for a floppy error if you enabled this item.

► Model Name

Model name of this product.

► BIOS Version

It displays the current BIOS version. User can check this information and discuss with the field
service people if a BIOS upgrade is needed.

► Memory

This item displays the current memory size. The size is depending on how many memory mod-
ules were installed in your system before powering on.

► MAC Address

This item shows the onboard LAN MAC address.

► CPU Name

It displays the current CPU name.

Mapping Table :

With PATA IDE drives

Without PATA IDE drives

With PATA IDE

drives

OnChip ATA Devices

OnChip ATA

Devices

SATA#1 Configuration
Compatible/Enhanced

SATA#1 Configuration

Disabled

SATA#1 Configuration
Compatible/Enhanced

SATA#1 Configuration

Disabled

Configure

SATA#1 as

SATA#2 Configuration

RAID/AHCI

Enhanced

Disabled

Enhanced

Disabled

Enhanced

Disabled

Enhanced

Disabled

4 ports

6 ports

Primary IDE Master

SATA 1

SATA 5

IDE0

SATA 1

SATA 5

IDE0

Primary IDE Slave

SATA 2

IDE1

SATA 2

IDE1

Secondary IDE Master

SATA 3

SATA 6

SATA 3

SATA 6

Secondary IDE Slave

SATA 4

Third IDE Master

SATA 5

IDE0

SATA 5

IDE0

Third IDE Slave

IDE1

Forth IDE Master

SATA 6

Forth IDE Slave

Fifth IDE Master

IDE0

Fifth IDE Slave

IDE1
