63
4
2.2 HW Monitor - fan
Move the mouse on the fan icon , its menu appears. Click on the fan icon to get into the fan
setting menu. It allows you to set the low/high limits of the CPU, NB and System fan speeds, and
to enable the alert function. If the current fan value is lower than the low limit or higher than the
high limit, then a buzzer sounds.
Fan control has three operating modes :
By full speed :
Running at full speed.
By Duty-Cycle :
The fan speed
is controlled by setting the percentage to the fan duty (between 0% ~ 100%).
By smart fan:
Fan speed is controlled by the system automatically.
2.3 HW Monitor - Temperature
Move the mouse on the temperature icon , its menu appears. Click on the temperature
icon to get into the temperature setting menu. It allows you to set the low/high limits of CPU tem-
perature, System temperature and NB temperature, and to enable the alert function. If the current
temperature value is lower than the low limit or higher than the high limit, then a buzzer sounds.
Click these
buttons to set
the low limit
fan speed
Click these
buttons to set
the high limit
fan speed
Click it to en-
able the alert
function
Show current
fan speeds
Click these but-
tons to set the
low limit CPU
temperature
Click these
buttons to set
the high limit
CPU tempera-
ture
Click it to en-
able the
alert function
Show current
temperatures
