52
3
Warning: Adjusting the voltage beyond the IOH default 1.506 VCCA voltage could result in
damage to the IOH.
► SB Voltage Setting
This item is used to set SB Voltage. The default voltage is 1.500V.
► IOH Core Voltage Setting
Isolated power for ICH core voltage, default voltage is 1.506V.
Warning: Adjusting the voltage beyond the ICH default voltage could result in damage to the
ICH.
********Affect Memory MHz********
► DRAM Voltage Setting
The maximum voltage available for adjustment is 2.86V.
Warning: Adjusting the voltage beyond the memories default voltage could result in damage to
the memory controller, the default voltage is 1.60V
► DIMM1/2/3 C-Addr Ref. Voltage & DIMM1/2/3 DQ Ref. Voltage
C-Addr(Command-address) and DQ(Data line) reference voltage is reference DRAM voltage,
the actual reference voltage will be DRAM voltage multiply this item value.
