Q-See QSDF8204 User Manual
Qsdf8204
Table of contents
Document Outline
- CONTENTS
- Introduction
- Panel Functions
- Basic Operation Guide
- How to Start DVR
- Main Menu Setting
- Press the "Menu" button, input username and password in the Login interface (as Fig. 3.1), and then you will see the Main Menu (as Fig. 3.2).
- Move the cursor, and the selected items will be highlighted in yellow
- Press "Enter" key to enter the sub-menu, and press "Menu" key to get back to Main Menu
- Basic Configuration
- Live Configuration
- Record Configuration
- VIDEO RESOLUTION
- RECYCLE
- PRERECORD TIME
- TIME STAMP
- CHANNEL
- VIDEO QUALITY
- AUDIO
- SCHEDULE RECORD
- Move the cursor to "SCHEDULE RECORD" option
- Check "SCHEDULE RECORD", and the “Setup” window will pop up.
- Press "Setup" to enter the Schedule Setup menu.
- In the Schedule Setup menu, move the cursor to select a day, and check “whole day” if you want to record all of the time.
- If you only want to record certain time periods press "Enter" key to set up time.
- Press "+" and "-" buttons on the front panel to modify the time.
- Press "Enter" key to confirm the setup.
- FRAME RATE SETUP
- COPY TO
- Alarm Configuration
- PTZ Configuration
- CHANNEL
- BAUDRATE
- PROTOCOL
- ADDR
- PRESET
- Press "SET" button to enter Preset submenu shown in Fig. 3.15. There are 16 preset points that can be set in every channel.
- In Preset submenu, press "Enter" button to switch the preset point needing to be reset.
- Press "ADJUST" button to enter PTZ mode.
- On the front panel, press "ZOOM", "FOCUS", "SPEED", "IRIS", "+" (MENU) and "-" (PTZ) buttons to modify the position of the preset point.
- Press "UP", "DOWN", "RIGHT" and "LEFT" buttons to rotate the Speed Dome.
- Press "ESC" button to come back to Preset menu.
- Press "SAVE" button to save the setting, and press "CANCEL" to discard the setting.
- COPY TO
- User Configuration
- AUTHORIZATION CHECK
- USER
- PASSWORD
- AUTHORIZATION
- Move the cursor to "User" option, then press "Enter" key to switch to the user whose authorization you want to modify.
- Move the cursor to "SETUP" button on the screen.
- Press "Enter" key, Authority Setup menu (refer to Fig. 3.17) will pop up.
- In the Authority Setup menu, move the cursor to "DEFAULT".
- Press "Enter" key. The default authorization will be set.
- NEW USER
- DELETE USER
- Network Configuration
- Manager Tools
- SHUTDOWN SYSTEM
- DISK MANAGER
- SYSTEM LOG
- SYSTEM INFORMATION
- UPDATE FIRMWARE
- LOAD DEFAULT
- IMPORT CONFIGURATION & EXPORT CONFIGURATION
- This function is used to help users manage multiple DVRs conveniently. When users need to set up the same parameters in more than one DVR, they can copy one DVR’s setting to all others without setting them up one by one.
- EXPORT CONFIGURATION can copy one DVR’s parameter settings to a USB flash drive; and then use IMPORT CONFIGURATION to input the settings copied onto the USB flash drive from the first DVR to another DVR.
- CLEAR ALARM OUT
- Shortcut Menu
- PTZ
- Search
- PLAYBACK
- Select the Date
- Search by Time
- Search by Event
- In Playback submenu, select the camera and date. The dates having recorded events are highlighted in red.
- Move the cursor to event option.
- Press the "Down" button to move the cursor to "EVENTS" button in the submenu.
- Press "Enter" key to enter the event list.
- Vies the list information.
- Choose an event record.
- Press "Enter" key to play back the record
- Press "Stop" button to get back to live display mode.
- BACKUP & VIEW BACKUP
- DELETE
- LOCK/UNLOCK
- PLAYBACK
- Information
- Other
- Remote Surveillance
- Accessing DVR
- Accessing DVR Over a Network
- Input IP address, Subnet, and Gateway, please refer to section 3.2.7 Network Configuration. If using DHCP, please enable DHCP in both of DVR and router.
- Enter “Video” submenu to set network video parameters like resolution, frame rate, etc.
- Open an Internet Explorer browser on a computer on the same network. Input the IP address of the DVR in an Internet Explorer textbox and hit enter.
- Internet Explorer will download ActiveX automatically. (Notice: Internet Explorer must be set up to permit downloading ActiveX controls. Please refer to Q7 in FAQ chapter) Then a window pops up and asks for user name and password.
- Input name and password correctly, and enter. It will show the picture below:
- Accessing DVR Over the Internet
- Accessing DVR Over a Network
- Main Interface
- Remote Playback and Search
- Remote Playback
- Other Functions
- BACKUP
- TIME BACKUP
- EVENT BACKUP
- Select time and record type.
- Select camera.
- Press "Browse…" button to select the folder with saved backup files.
- Select cameras that you want to backup.
- Select the type of backup file.
- Click "Select Event" button to enter Select Event window shown as Fig 4.9 Select Event.
- Click "OK" button to run the backup.
- LOCK /UNLOCK
- Click button to enter Remote Lock window as Fig 4.10 Remote Lock.
- Select time and record type.
- Select camera.
- Click "Select Event" button, system will find the corresponding event and pop up the LOCK EVENT window shown as Fig 4.11 Lock Event.
- Check the check box to change lock status.
- Click "OK" button to confirm the operation.
- BACKUP
- Remote DVR Configuration
- Basic Configuration
- Live Configuration
- Record Configuration
- Parameter Setting
- Schedule Record
- Click the check box of the Schedule Record, and it will be active. The default schedule time is every day.
- Click "Set Schedule" button, and Schedule Configuration window will pop up as Fig 4.17 Schedule Configuration.
- Click "Eraser" button and click on the weekday schedule to delete the time; Click "Add" button and click on the weekday schedule to add the time.
- Alarm Configuration
- Network Configuration
- User Configuration
- Management Tools
- Remote PTZ
- Accessing DVR
- Operation with a Mouse
- Mobile Surveillance
- By Smart Phone with WinCE Operating System
- First, activate the network access on the mobile phone, and then run “Internet Explorer”.
- Input the public IP address you need to use to connect as shown below (see 4.1.2 Accessing the DVR over the Internet):
- Click on the software name. A dialog box will pop up.
- Click “Yes” to download and install.
- PCam will be opened after installed.
- Input the server’s address, ID, and password respectively in the columns of “Server”, “User”, and “Password”. Then click “Go” to login to the DVR. It will show the picture if accessed successfully.
- Camera 1 is the default display after login. Change the camera in the drop down menu of “Channel”.
- By Smart Phone with Symbian Operating System
- First, enable the network access on mobile phone, and then run Web browser.
- Input the DVR server’s IP address in a new-built bookmark (see 4.1.2 Accessing the DVR over the Internet). Click this bookmark to connect with the DVR.
- A welcome window will pop up with a link to download the software. Click “install package” to download.
- The security window will pop up after downloaded and ask if you want to install the package. Click YES to install.
- A Scam shortcut icon appears on the system menu after finished.
- Run Scam program.
- Click Options--->Settings to enter login interface.
- Input the server’s address, ID and password respectively. Then click OK to login to the DVR. (See 4.1.2 Accessing the DVR over the Internet)
- It will show the camera after accessing successfully.
- By Smart Phone with WinCE Operating System
