QSDF8204 Digital Video Recorder User Manual
58
Appendix A Standards & Specifications
Model 4 Channel
VIDEO
Input Level
4
×BNC 1.0Vp-p±10%.75Ohm
Video Standard NTSC / PAL
Video Output
1
×BNC 1.0Vp-p±10%.75Ohm，1×S-Video
Screen Split Control 1, 4Screen
Display Resolution NTSC 720x480
PAL 720x576
Speed NTSC 120FPS
PAL 100FPS
AUDIO
Compression
PCM
Audio In/ Out 2CH/ 1CH
Input Level TBD(0.5~1.4Vp-p@20Kohm)
RECORDING
Compression
H.264
Compression bit rate 64kbps-512kbps
Resolution NTSC
352(H)x240(V)(CIF); 70
4×480(D1)
PAL
352(H)x288(V)(CIF); 70
4×576(D1)
Speed NTSC Max 120FPS(CIF); 30(D1)
PAL Max 100FPS(CIF); 25(D1)
Mode Manual, Schedule, Motion detection, Sensor
Motion detection 16*12 detection areas can setup
HDD interface
SATA
×1
SEARCHING
Searching Method
Time, Event
REMOTE SURVEILLANCE
Monitoring Environment
Self-carried LCD monitor, IE, CMS, SMART PHONE, PDA,
etc.
ALARM
Sensor Input
4 Ports
Alarm Output 1-Out (Programmable), Terminal
Motion Detection Available for Each Camera with Multi-detection Level
CONNECTOR
Video Input
BNC
×4
Main Monitor Output
BNC
×2(Parallel), S-Video×1
Audio Input (Mono)
RCA
×2
Audio Output (Mono)
RCA
×1
Sensor Input Terminal Block
Alarm Output Terminal Block
PTZ (RS-485) 2 Pins Terminal Block
Ethernet RJ-45, 10/100Mbps
USB 1.1 2 Ports
ELECTRICAL
Power Source
DC 12V
Power Consumption TDP 21Watt
BACKUP
Digital Backup
Network, USB 1.1
OTHERS
OS
Embedded Linux operation system
Duplexer or Triplex Triplex
