EZII Escape Computer Command Set
44
D36 48 Rev G
November 30, 2009
^ TEST ^ CAL ^
111111 222222 333333 444444 555555 666666 >
1 1 2 2 3 3 4 4 5 5 6 6
111111 222222 : 333333 444444 : 555555 666666 >
1 1 2 2 3 3 4 4 5 5 6 6
111111 222222 333333 . 444444 . 555555 . 666666 >
v v v lb kg v
Oa - Remote Annunciator Command:
This command displays annunciators on the Cab Controls 6 character display.
This command includes the following information:
Start new command:
Command identifier:
Oa
Data format to send:
xxxyyy (xxx = 3 byte value for positive image, yyy=3 byte value for
negative image).
End of command:
The figure below represents the EZII LCD. The six digits are outlined using their number (ie. far left is digit
1, far right is digit 6).
Motion
ID
Net Load Gross
To turn on an annunciator, such as “lb” below digit 5, first find the Annunciator code for “lb” (Hex value
0x002000) from the table below, then "logically" AND this with Hex value 0x404040 to make Hex value
0x406040. This converts it into a three byte ASCII value "@`@" that can be sent to the Cab Control. To have
the “lb” annunciator stay on continuously, send "
"
Three (3) Byte Data Format for Remote annunciators (Codes are shown as Hex values):
Annunciator
Hex Code
Annunciator
Hex Code
Motion-Up arrow above 1.
0x010000
CAL between digits 4 & 5.
0x001000
Net-Down arrow below digit 1.
0x020000
lb (pounds) below digit 5.
0x002000
TEST above digit 2.
0x040000
kg (kilograms) below digit 5.
0x000001
Down arrow below digit 2.
0x080000
Period between digits 5 & 6.
0x000002
Colon between digits 2 & 3.
0x100000
Gross-Down arrow below digit 6.
0x000004
Period between digits 3 & 4.
0x200000
Right arrow #3, bottom.
0x000008
Up arrow between digits 3 & 4.
0x000100
ID-Right arrow #2, middle.
0x000010
Load-Down arrow below digit 4.
0x000200
Print-Right arrow #1, top.
0x000020
Colon between digits 4 & 5.
0x000400
All bits ON.
0x7F7F7F
Period between digits 4 & 5.
0x000800
All bits OFF.
0x404040
Remote Annunciator Command Response: No response is sent from the Cab Control.
Remote Annunciator Command Example:
The following command string
annunciator to be displayed continuously.
