BIOS Setup
System BIOS Cacheable
When this field is enabled, accesses to the system BIOS ROM ad-
dressed at F0000H-FFFFFH are cached, provided that the cache
controller is enabled. The larger the range of the Cache RAM, the
higher the efficiency of the system.
Memory Hole At 15M-16M
In order to improve system performance, certain space in memory
can be reserved for ISA cards. This memory must be mapped into
the memory space below 16MB. When enabled, the CPU assumes
the 15-16MB memory range is allocated to the hidden ISA address
range instead of the actual system DRAM. When disabled, the CPU
assumes the 15-16MB address range actually contains DRAM
memory. If more than 16MB of system memory is installed, this field
must be disabled to provide contiguous system memory.
PCI Express Root Port Func
The settings on the screen are for reference only. Your version may not be
identical to this one.
Phoenix - AwardBIOS CMOS Setup Utility
PCI Express Root Port Func
PCI Express Port 1
PCI Express Port 2
PCI Express Port 3
PCI Express Port 4
PCI Express Port 5
PCI Express Port 6
PCI-E Compliancy Mode Item Help
Menu Level XX
Auto
Auto
Auto
Auto
Auto
Auto
v1.0a
↑↓→← : Move Enter: Select F1: General Help +/-/PU/PD: Value F10: Save ESC: Exit
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
PCI Express Port 1 to PCI Express Port 6
These fields are used to enable or disable the PCI Express port func-
tion.
PCI-E Compliancy Mode
This field is used to select the mode for the PCI Express add-in
card.
