NS9210 Processor Module Hardware Reference
C h a p t e r 2
LEDs
The RJ-45 connector has two LEDs located near the outer lower corners of the
connector. These LEDs are not programmable.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
P e r i p h e r a l ( e x p a n s i o n ) h e a d e r s
LED
Description
Yellow
Network activity (speed): Flashing when network traffic detected; Off when no network
traffic detected.
Green
Network link: On indicates an active network link; Off indicates that no network link is
present.
Peripheral Application Header, X33
