NS9210 Processor Module Hardware Reference
C h a p t e r 2
Standard JTAG
ARM connector,
X13
The standard JTAG ARM connector is a 20-pin header and can be used to connect
development tools such as Digi’s JTAG Link, ARM’s Multi-ICE, Abatron BDI2000, and
others.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
P o E m o d u l e c o n n e c t o r s - I E E E 8 0 2 . 3 a f
The development board has two PoE module connectors, X9 and X26. The PoE
module is an optional accessory item that can be plugged on the development board
through the two connectors:
X9, input connector: Provides access to the
PoE
signals coming from the
Ethernet interface.
X26, output connector: Provides the output power supply from the PoE
module.
Pin
Signal
Pin
Signal
1
+3.3V
2
+3.3V
3
TRST#
4
GND
5
TDI
6
GND
7
TMS
8
GND
9
TCK
10
GND
11
RTCK (optional)
12
GND
13
TDO
14
GND
15
SRESET#
16
GND
17
No connect
18
GND
19
No connect
20
GND
