NS9210 Processor Module Hardware Reference
C h a p t e r 2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
U s e r i n t e r f a c e
The NS9210 Processor Module Development board implements two user buttons and
two user LEDs in addition to those provided on the module.
The user LEDs on the development board can be enabled or disabled by correctly
setting jumper J5&6.
The table below shows which NS9215 GPIO is available for implementing the user
interface.
Signal name
GPIO used
Comments
USER_BUTTON1
GPIO81
10k pull-up to +3.3V on the
development board
USER_LED1#
GPIO82
USER_BUTTON2
GPIO84
10k pull-up to +3.3V on the
development board
USER_LED2#
GPIO85
