Digi NS9210 User Manual
Page 30
30
NS9210 Processor Module Hardware Reference
C h a p t e r 1
GPIO31
D15
TXDD
Reserved
Reserved for upper data
lines
GPIO32
MII_MDC
PIC_0_GEN_IO[0]
Reserved
MII Interface
GPIO33
MII_TXC
PIC_0_GEN_IO[1]
Reserved
MII Interface
GPIO34
MII_RXC
PIC_0_GEN_IO[2]
Reserved
MII Interface
GPIO35
MII_MDIO
PIC_0_GEN_IO[3]
Reserved
MII Interface
GPIO36
MII_RXDV
PIC_0_GEN_IO[4]
Reserved
MII Interface
GPIO37
MII_RXER
PIC_0_GEN_IO[5]
Reserved
MII Interface
GPIO38
MII_RXD0
PIC_0_GEN_IO[6]
Reserved
MII Interface
GPIO39
MII_RXD1
PIC_0_GEN_IO[7]
Reserved
MII Interface
GPIO40
MII_RXD2
PIC_1_GEN_IO[0]
Reserved
MII Interface
GPIO41
MII_RXD3
PIC_1_GEN_IO[1]
Reserved
MII Interface
GPIO42
MII_TXEN
PIC_1_GEN_IO[2]
Reserved
MII Interface
GPIO43
MII_TXER
PIC_1_GEN_IO[3]
Reserved
MII Interface
GPIO44
MII_TXD0
PIC_1_GEN_IO[4]
Reserved
MII Interface
GPIO45
MII_TXD1
PIC_1_GEN_IO[5]
Reserved
MII Interface
GPIO46
MII_TXD2
PIC_1_GEN_IO[6]
Reserved
MII Interface
GPIO47
MII_TXD3
PIC_1_GEN_IO[7]
Reserved
MII Interface
GPIO48
MII_COL
Reserved
Reserved
MII Interface
GPIO49
MII_CRS
Reserved
Reserved
MII Interface
GPIO50
MII_PHY_Int
PIC_1_CLK (I)
PIC_1_CLK(0)
MII Interface
GPIO51
DCDB# (dup)
PIC_0_BUS_1[8]
PIC_1_BUS_1[8]
DCDB#
GPIO52
CTSB# (dup)
PIC_0_BUS_1[9]
PIC_1_BUS_1[9]
CTSB#
GPIO53
DSRB# (dup)
PIC_0_BUS_1[10]
PIC_1_BUS_1[10]
DSRB#
GPIO54
RXDB (dup)
PIC_0_BUS_1[11]
PIC_1_BUS_1[11]
RXDB
GPIO55
RIB# (dup)
PIC_0_BUS_1[12]
PIC_1_BUS_1[12]
RIB#
GPIO56
RTSB# / 485CTLB
(dup)
PIC_0_BUS_1[13]
PIC_1_BUS_1[13]
RTSB#
GPIO57
TXCLKB (dup) /
DTRB# (dup)
PIC_0_BUS_1[14]
PIC_1_BUS_1[14]
DTRB#
GPIO58
TXDB (dup)
PIC_0_BUS_1[15]
PIC_1_BUS_1[15]
TXDB
GPIO59
DCDD# (dup)
PIC_0_BUS_1[16]
PIC_1_BUS_1[16]
DCDD#
GPIO60
CTSD# (dup)
PIC_0_BUS_1[17]
PIC_1_BUS_1[17]
CTSD#
Port
name,
Function
03
Alternate function
00
Alternate function
01
Alternate
function 02
Alternate
function 04 (only
GPIO00...GPIO15)
On module, default
used as
