www.digiembedded.com 21
57 I/O PIC_0_BUS_0[14]/
PIC_1_BUS_0[14]/
QDCI (dup)/
GPIO94
58 I/O PIC_0_BUS_0[15]/
PIC_1_BUS_0[15]/
QDCQ (dup)/
GPIO95
59 I/O PIC_0_BUS_1[0]/
PIC_1_BUS_1[0]/
PIC_0_CAN_RXD
GPIO96
60 I/O PIC_0_BUS_1[1]/
PIC_1_BUS_1[1]/
PIC_0_CAN_TXD
GPIO97
61 I/O PIC_0_BUS_1[2]/
PIC_1_BUS_1[2]/
PIC_1_CAN_RXD
GPIO98
62 I/O PIC_0_BUS_1[3]/
PIC_1_BUS_1[3]/
PIC_1_CAN_TXD
GPIO99
63 I/O PIC_0_BUS_1[4]/
PIC_1_BUS_1[4]/
PWM4/
GPIO100
64 I/O PIC_0_BUS_1[5]/
PIC_1_BUS_1[5]/
EIRQ3/
GPIO101
65 I/O PIC_0_BUS_1[6]/
PIC_1_BUS_1[6]/
I2C_SCL (dup)/
GPIO102 4k7 pull-up on module
66 I/O PIC_0_BUS_1[7]/
PIC_1_BUS_1[7]/
I2C_SDA (dup)/
GPIO103 4k7 pull-up on module
X2 pin
number
Type Module functionality Usage on
Development board Comments
