48

NS9210 Processor Module Hardware Reference

C h a p t e r 2

Serial port C TTL
interface

The serial (UART) port C interface is a TTL interface connected to a 2x5 pin, 0.1”
connector, X5. The connector supports only TTL level.

The serial port C interface corresponds to the NS9215 UART port C. The signals are
shared with the

HDLC

interface.

Serial port C pins are allocated as shown:

Note: By using GPIO12 as RIC#, be sure to populate a series resistor on the
baseboard. This is necessary to avoid conflict between the default configuration of
the GPIO when booting (RESET_DONE / output) and the chosen configuration once
booted (RIC# / input).

By default, Serial C signals are configured to their respective GPIO signals, except
for GPIO12. It is the responsibility of the driver to configure them properly.

Pin

Function

Defaults to

1

DCDC#/TXCLKC

GPIO8.

2

DSRC#

GPIO10.

3

RXDC#

GPIO11

4

RTSC#/RXCLKC

GPIO13

5

TXDC

GPIO15

6

CTSC#

GPIO9

7

DTRC#/TXCLKC

GPIO14

8

RIC#/RXCLKC/GPIO 12

RESET_DONE See note

9

GND

10

3.3V
