20 NS9210 Processor Module Hardware Reference
C h a p t e r 1
47 I/O PIC_0_CTL_IO[3]
PIC_1_CTL_IO[3]
Timer5_In/
GPIO79
48 I/O PIC_0_BUS_0[0]
PIC_1_BUS_0[0]
Timer6_In (dup)/
GPIO80
49 I/O PIC_0_BUS_0[1]
PIC_1_BUS_0[1]
Timer7_In (dup)/
GPIO81
50 I/O PIC_0_BUS_0[2]
PIC_1_BUS_0[2]
Timer8_In (dup)/
GPIO82
51 I/O PIC_0_BUS_0[3]
PIC_1_BUS_0[3]
Timer9_In (dup)/
GPIO83
52 I/O PIC_0_BUS_0[4]
PIC_1_BUS_0[4]
Timer0_Out/
GPIO84
53 I/O PIC_0_BUS_0[5]
PIC_1_BUS_0[5]
Timer1_Out/
GPIO85
54 I/O PIC_0_BUS_0[6]
PIC_1_BUS_0[6]
Timer2_Out/
GPIO86
55 I/O PIC_0_BUS_0[7]
PIC_1_BUS_0[7]
Timer3_Out/
GPIO87
56 I/O PIC_0_BUS_0[13]/
PIC_1_BUS_0[13]/
Timer9_Out (dup)/
GPIO93
X2 pin
number
Type Module functionality Usage on
Development board Comments
